Introduction
Thank you for purchasing a StarTech.com Slot Saver PCI card to your computer. This
product allows you to add 2 serial ports and 1 ECP parallel port to your computer using a
space-saving single card design. Perfect for small form factor and other reduced
footprint case designs, you can add support for your existing peripherals and devices
using Plug and Play setup and ports that often outperform integrated serial and parallel
ports.
Features
• Fully complies with the IEEE-1284 standard and supports BPP, SPP, EPP, and ECP
parallel data transfer modes
• Fast data transfer rates often outperform built-in ports (up to 960 Kbits/sec. on serial
ports, 1.5 Mbits/sec. on the parallel port)
• Complies with Plug and Play standards
• Backed by StarTech.com's lifetime warranty

Before You Begin

To ensure a quick and easy card installation, please read through this section carefully
before attempting to install the card.
WARNING! PCI cards, like all computer equipment, can be severely damaged by static
electricity. Be sure that you are properly grounded before opening your computer case or
touching your PCI card. StarTech.com recommends that you wear an anti-static strap
when installing any computer component. If an anti-static strap is unavailable, discharge
yourself of any static electricity build-up by touching a large grounded metal surface
(such as the computer case) for several seconds. Also be careful to handle the PCI card
by its edges and not the gold connectors.
System Requirements
• A computer with an available PCI slot
• Minimum Operating System Requirements: Windows
95/98/98SE/ME/NT/2000/XP/2003 or later, DOS, Linux
Contents
This package should contain:
• 1 x PCI2S1P PCI card and separate parallel port (with ribbon cable)
• 1 x Installation CD
• 1 x Instruction Manual
