StarTech.com PCI2S485LP User Manual

2 Port Low Profile PCI RS-422/485 Card
PCI2S485LP
PCI2S485LP15
Packaging Contents
• 1 x PCI2S485LP/15 PCI Card
• 1 x Driver CD
• 1 x User Manual
System Requirements
• Available PCI or PCI-X port
• Microsoft Windows
Installation
WARNING! PCI cards, like all computer equipment,
can be severely damaged by static electricity. Be sure
that you are properly grounded before opening your
computer case or touching your card. StarTech.com
recommends that you wear an anti-static strap when
installing any computer component. If an anti-static
strap is unavailable, discharge yourself of any static
electricity build-up by touching a large grounded metal
surface (such as the computer case) for several sec-
onds. Also, be careful to handle the card by its edges
and not the gold connectors.
Hardware Installation
1. Turn your computer off and any peripherals connected
to the computer (ie. Printers, external hard drives, etc.).
Unplug the power cable from the rear of the power supply
on the back of the computer.
2. Remove the cover from the computer case.
3. Locate an open PCI or PCI-X slot and remove the metal
cover plate on the rear of the computer case.
4. Insert the card into the open PCI or PCI-X slot and screw
the bracket to the rear of the case.
5. Place the cover back onto the computer.
6. Insert the power cable into the socket on the power
supply.
2000/XP/Vista, Linux
®
Dip Switch Configuration
Mode Switch 1
RS-485
RS-422
Driver Installation
Windows 2000/XP
®
1. When the Found New Hardware Wizard appears, click
Next to continue.
2. Insert the Driver CD (included) into the CD/DVD-ROM
drive. Select Search for the best driver for your device
(recommended) then click on Next.
3. Select Specify the location... and type d:\Win2K/XP
(where d:\ designates the location of the CD/DVD-ROM
drive). in the text box provided, and click Next.
4. Click on Next, then Finish.
5. Remove the Driver CD from the CD/DVD-ROM drive and
re-start the computer when prompted.
Windows Vista
Once the computer has rebooted:
1. Insert the Driver CD (included) into the CD/DVD-ROM
drive. At the Found New Hardware window, click on Lo-
cate and install driver software (recommended), and click
Next on the screen that follows
2. When a message appears indicating that the publisher of
the driver cannot be verified, please click on Install this
driver software anyways.
3. Once installation is complete, you will be notified that
NetMos 98xx PCI Multi-I/O Controller has been installed
successfully. Please repeat steps 2 and 3 as necessary.
Switch 2 Switch 3
ON ON
ON ON
Switch 4
OFF OFF
ON ON
