Measurement results may be transferred from memory of the measuring unit of ISOMET2114 into a
personal computer via USB communication interface. Supporting software is supplied with
ISOMET2114 on USB MSD (USB key) in two application files: CDM20814_Setup.exe and
ResReadout_I2114.exe.
Application ResReadout_I2114.exe enables
 Uploading results from ISOMET2114 to connected PC via USB communication interface
 Deleting all results from memory of ISOMET2114 connected to PC via USB port.
Before the first running of the application ResReadout_I2114.exe, driver for installing virtual
communication port should be installed by running CDM20814_Setup.exe. For complete installation,
the application CDM20814_Setup.exe must be run after finishing the first part of the installation once
more.
Minimum System Requirements:
 processor Intel Pentium 166 MHz or higher (PII 400 MHz recommended)
 operation system Microsoft Windows XP or newer version
 operation memory 128 MB RAM (256 MB recommended)
 free hard disk space 30 MB
 USB port
 VDA Monitor and mouse or other pointing device
Procedure for installing the data transfer support
Run the application file CDM20814_Setup.exe. The installation will take approximately 10 seconds.
Run the application file CDM20814_Setup.exe once more. The additional installation will take
approximately 25 sec.
Copy the file ResReadout_I2114.exe from installation USB key to the HD of your PC.
Transferring data into PC
Before running the application file ResReadout_I2114.exe, connect the measuring unit to a PC USB
port, by means of the supplied USB interconnection cable and turn it on.
After running the exe file ResReadout_I2114.exe, the following window will be displayed on the
screen.
www.appliedp.com

5. Software data exchange

5.1 Software Installation
23
