ISOMET 2114
User's Guide
3.4.1 Locking Mechanism
Pulling on the cable or on the back nut causes
Pulling on the outer plug housing disengages the
the locking fingers to grip tighter into the groove
locking fingers from the receptacle groove and
inside receptacle (socket). A separation is
the connector separates easily.
virtually impossible.
3.4.2 Cable Connecting
Connecting
Connected cable
10
www.appliedp.com
