LANCOM 1751 UMTS
Chapter 7: Providing dial- in access
Gateway: If defined in the LANCOM VPN Router, a DynDNS name is used
here, or alternatively the IP address
FQDN: Combination of the name of the connection, a sequential number
and the internal domain in the LANCOM VPN Router.
Domain: If defined in the LANCOM VPN Router, the internal domain is
used here, or alternatively a a DynDNS name or IP address
VPN IP networks: All IP networks defined in the device as type 'Intranet'.
Preshared key: Randomly generated key 16 ASCII characters long.
Connection medium: The LAN is used to establish connections.
VoIP prioritization: VoIP prioritization is activated as standard.
Exchange mode: The exchange mode to be used is 'Aggressive Mode'.
IKE config mode: The IKE config mode is activated, the IP address infor-
mation for the LANCOM Advanced VPN Client is automatically assigned
by the LANCOM VPN Router.
55
