AMQ ACTIV Installation Manual
Height adjustable sit-to-stand benching
Hide thumbs
Also See for ACTIV:
- User manual (13 pages) ,
- Assembly manual (16 pages) ,
- User & troubleshooting manual (12 pages)
Related Manuals for AMQ ACTIV
Summary of Contents for AMQ ACTIV
- Page 1 Phase 1 Footer & Base Plate Assembly ACTIV sit-to-stand benching - Installation Guide ACTIV height adjustable benching installation guide 915 Walsh Avenue / Santa Clara, CA 95050 (877) 801-0370 amqsolutions.com...
- Page 2 Index ACTIV sit-to-stand benching - Installation Guide Materials and Tools ..............3 Assembly Outline ...............4 Assembly Instructions Legs and Bar Assembly .............5 Legs and Beam Assembly ............6 Leg Bases Cover Assembly ............7 Stretcher Bars and Cantilever Assembly ....... 8-9 Multiple Configurations ............10 Worksurface Mounting .............11...
-
Page 3: Materials And Tools
Materials and Tools Preparation 1. Activ Benching Components Layout ACTIV sit-to-stand benching - Installation Guide Hardware Cable straps allen keys #4-1 #4-2 #5-1 #5-2 wood screws Leg-1&2 x 2 sets cantilevers x 2 sets socket screws stretcher bar assembly x 2 sets... -
Page 4: Assembly Outline
Assembly Outline Preparation ACTIV sit-to-stand benching - Installation Guide Assembly outline Assembly Parts # 1. Legs and bars assembly 1 & 2 2. Leg bases and beam assembly 3, 4 & 5 6 & 7 3. Leg bases cover assembly 8 &... -
Page 5: Legs And Bar Assembly
Phase 1 Legs and Bar Assembly ACTIV sit-to-stand benching - Installation Guide Lay out the legs and stretcher bars and #5-1 screws. Place legs on floor upside down. Take each crossbar and attach to the legs (make sure the crossbar is also upside down –... - Page 6 Phase 2 Leg Bases and Beam Assembly ACTIV sit-to-stand benching - Installation Guide Insert the beam into the slot of the leg crossbar, 3. Leg bases and beam assembly tilting it so that the beam slips into the notches. Take an anchoring block and insert to the underside of the beam as shown.
-
Page 7: Leg Bases Cover Assembly
Phase 3 Leg Bases Cover Assembly ACTIV sit-to-stand benching - Installation Guide Take your #6 screws and insert to the Inner Bracket, 4. Leg bases cover assembly wedging the inner bracket up to the beam. Use #4-1 screws unless indicated other wise Place each crossbar cover on the leg and snap into place, pushing the outside. -
Page 8: Stretcher Bars And Cantilever Assembly
Phase 4 Stretcher Bars and Cantilever Assembly ACTIV sit-to-stand benching - Installation Guide 5. Stretcher bars and cantilever assembly -1 Place each stretcher bar over the legs so that the open ends slide over the motors, making sure the tightening screws are underneath the Stretcher Bars. -
Page 9: Stretcher Bars And Cantilever Assembly
6. Stretcher bars and cantilever assembly - 2 Phase 4 Stretcher Bars and Cantilever Assembly ACTIV sit-to-stand benching - Installation Guide (continued) Place the Cantilevers on each end of the stretcher bar and screw in, noting the size of screw in the diagram (indicated with a 1 or 2). -
Page 10: Multiple Configurations
Phase 5 Multiple Configurations ACTIV sit-to-stand benching - Installation Guide 7. Multiple Con guration Remove the center screw underneath the crossbar cover if already mounted. Place Connector Box over cutout, aligning the hook flange, slipping upwards, to attach. Screw with #4 screws. -
Page 11: Worksurface Mounting
Phase 6 Worksurface Mounting ACTIV sit-to-stand benching - Installation Guide 9. Work-surface mounting Use #4-1 screws Place each worksurface, and tighten into place. Note that the worksurface depth should be center aligned with the cantilever depth and should have equal amount of overhang on each end. - Page 12 Phase 7 Electrical - Phase 3 ACTIV sit-to-stand benching - Installation Guide Take a junction block and snap in 2 receptacles on each side. 8. Electrical - Phase3 Lower the junction block assembly into the beam canal with the receptacles facing up and then rotate in a clockwise direction to Mount electrical junction box with brackets and insert data plate adapter snap the receptacle in to the receptacle cut outs.
-
Page 13: Trac
Phase 8 Electrical - 8trac ACTIV sit-to-stand benching - Installation Guide 8. Electrical - 8trac system Lower the 8trac-bracket and align its center screw holes with the pilot holes in the center of beam canal. Screw it down with the screws provided in the package. -
Page 14: Connecting Control Box And Power
Phase 9 Connecting Control Box and Power ACTIV sit-to-stand benching - Installation Guide 10. Connecting control and power Facing Make sure that the Left motor plugs into the direction M1 port and the Right motor plugs into the Handset M2 port. - Page 15 ACTIV sit-to-stand benching - Installation Guide Please contact cc@amqsolutions.com if you are missing any parts, have difficulty with assembly, or have any product related questions.
- Page 16 Footer & Base Plate Assembly ACTIV sit-to-stand benching - Installation Guide 5 Day Open Plan we provide exceptional experiences with reliable, easy interactions and successfully fulfilled orders in only 5 days 915 Walsh Avenue / Santa Clara, CA 95050 (877) 801-0370...
