INSTALLATION MANUAL
Bolden
Sensor Single Handle Pull Down
Kitchen Faucet
KSF-1616
www.kraususa.com I Toll Free: 1.800.775.0703 I © 2023 Kraus USA Plumbing LLC I REV. DEC 22, 2023

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Bolden KSF-1616 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Kraus Bolden KSF-1616

  • Page 1 INSTALLATION MANUAL Bolden Sensor Single Handle Pull Down ™ Kitchen Faucet KSF-1616 www.kraususa.com I Toll Free: 1.800.775.0703 I © 2023 Kraus USA Plumbing LLC I REV. DEC 22, 2023...
  • Page 2 Congratulations on the purchase of your new Please keep the box and packaging materials until your product is completely installed. If you have any questions, require technical assistance, or have any problems with your product: DO NOT RETURN TO STORE Please contact our Customer Service Team 1-800-775-0703 / customerservice@kraususa.com Have the model number available, and retain a copy of your receipt...
  • Page 3: Prior To Installation

    Make sure you have all necessary parts by checking the diagram and · parts list. If any part is missing or damaged, please contact Kraus Customer Service at 800-775-0703 for a replacement. Read all instructions and safety warnings and ensure you have all tools, ·...
  • Page 4 Diagram and Parts List J2 J3 F. Weight J. Battery Pack A. Spray Head B. Faucet Body G. Weight Clip J1. Battery Pack C. Washers H. Quick Connector J2. Screw I. Sensor Control Box D. Mounting Nut J3. Anchor E. Screws K.
  • Page 5: Faucet Dimensions

    Faucet Dimensions 11 1/8" [283.4mm] 4 3/8" 9 1/8" [111.1mm] [231.6mm] 3" 3" Ø2 1/8" [77.3mm] [75.0mm] [54.0mm] 3/8" compression 3/4" 2 7/8" [18.9mm] [74.2mm] Installer Tip:...
  • Page 6 Step 1: Remove mounting hardware old faucet. Clean the mounting surface. Remove washers (C), mounting nut (D) and screws (E) from faucet body (B). Step 2: Securing the faucet assembly Insert faucet body (B) through the hole in the sink or countertop. Install the washers (C) onto the threaded mounting shank.
  • Page 7 Step 3: Installing the sensor control box Install the data cable (1) to the control box connection (2). Ensure the arrows on the data cable and control box connection are aligned to one another to ensure proper installation. Ensure they are tightly Secure the connection by hand tightening the nut (3) in a clockwise direction onto the threaded sensor cable.
  • Page 8: Step 6: Installing The Battery Pack

    Step 5: Securing the faucet assembly Install the weight clip (G) at the point of the hose marking "weight here". Insert the weight (F) onto the weight clip (G) by sliding it down onto the weight clip (G). Step 6: Installing the battery pack To open the battery housing, squeeze the tabs (1) on the cover (2), then remove the cover (2).
  • Page 9 Step 7: Installing the battery pack Drill a hole in the wall using a 6mm (1/4 in.) diameter drill bit. Install the battery pack (J1) using the molly anchor (J3) and screw (J2) provided. Insert the battery pack cable (1) into the control box connection (2).
  • Page 10 Step 9: Flush faucet Flushing and checking for leaks: After the installation is complete, unscrew and remove on the water supply and allow both hot and cold water to run for at least one minute each. damage to internal parts. Check for leaks. Re-attach the spray head.
  • Page 11: Replacement Parts

    Replacement Parts Replacement Parts List Finish / Color Part # 1. Sprayer BB, MB, SFS, SFACB** KP27216 2. Screen Washer KP27208 3. Sprayer Hose BLBB, BLMB, BLSFS, KP27217 GRSFS, BLSFACB* 4. Connector WH** KP27074 5. Quick Connector Assembly KP27090 6. Cartridge Kerox K-35 KP27083 7.
  • Page 12: Troubleshooting

    Troubleshooting If you have followed the instructions carefully and your faucet still does not work properly, take the following corrective steps: When you turn the handle to But when you turn the handle This indicates that the cartridge the full on position, the water will turn on.
  • Page 13 When you turn the handle to However, when you move your Check whether the switch the full on position, the hand in front of the sensor, the button (1) is tight, if it is water will turn on. loose, tighten the switch button (1) should.
  • Page 14 Kraus warrants the structure and finish of the Faucet to be free from defects in material and workmanship under normal usage for as long as the original purchaser resides in the residence in which the Faucet was first installed.
  • Page 15 TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THIS WARRANTY DOES NOT COVER, AND KRAUS USA PLUMBING, LLC SHALL NOT BE LIABLE FOR, ANY SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES (INCLUDING LABOR CHARGES TO REPAIR, REPLACE, INSTALL OR REMOVE THIS PRODUCT), WHETHER ARISING OUT OF BREACH OF ANY EXPRESS OR IMPLIED WARRANTY, BREACH OF CONTRACT, TORT, OR OTHERWISE.
  • Page 16 IMPORTANT Register Your Kraus Product Activate Your Warranty Access Premium Customer Support Get Product Information REGISTER TODAY http://www.kraususa.com/registration www.kraususa.com...
