OWNER & INSTALLATION MANUAL
A f f i n i t y 3 0 G p
C o o k t o p
Evo Affi nity 30Gp
ffi
G
Manual-Controlled Gas Cooktop
With Standing Pilot Light
For Indoor Use Only
This appliance and its individual shutoff valve must be disconnected from the gas supply piping system
during any pressure testing of system at test pressures in excess of 1/2 PSI (3.5kPa).
Cleaning Instructions
Certifi cation: ANSI Z83.11-2016 / CSA 1.8-2016. OMNI Report # 0141GM003S
Part #: Commercial Models: 10-0070-NG | 10-0070-LP
evoamerica.com
Doc: 12-13-2017
Copyright © 2017
FINAL QR Code for Evo Cleaning.indd 1
11/19/2015 11:43:18 AM
Evo, Inc., 20560 SW 115th Ave., Tualatin, OR 97062 USA
Phone 503.626.1802 | Fax 503.213.5869 | www.evoamerica.com | support@evoamerica.com
Advertisement
Table of Contents
Related Manuals for Evo Affinity 30Gp
Summary of Contents for Evo Affinity 30Gp
- Page 1 Part #: Commercial Models: 10-0070-NG | 10-0070-LP evoamerica.com Doc: 12-13-2017 Copyright © 2017 FINAL QR Code for Evo Cleaning.indd 1 11/19/2015 11:43:18 AM Evo, Inc., 20560 SW 115th Ave., Tualatin, OR 97062 USA Phone 503.626.1802 | Fax 503.213.5869 | www.evoamerica.com | support@evoamerica.com...
-
Page 2: Installation Instructions
Be sure to read and carefully follow personal injury and / or property damage. all of the messages. Evo, Inc., 20560 SW 115th Ave., Tualatin, OR 97062 USA Phone 503.626.1802 | Fax 503.213.5869 | www.evoamerica.com | support@evoamerica.com... - Page 3 Complete Now For Future Reference Model #_______________________________ Serial # _________________________________ Date Purchased ________________________ Location Purchased _______________________ Date Installed __________________________ Location Installed _________________________ Evo, Inc., 20560 SW 115th Ave., Tualatin, OR 97062 USA Phone 503.626.1802 | Fax 503.213.5869 | www.evoamerica.com | support@evoamerica.com...
- Page 4 DURING THE FIRST FEW HOURS OF OPERATION IT IS NORMAL FOR OILS USED IN THE MANUFACTURING PROCESS TO BURN OFF AND GIVE AN ODOR OR SLIGHT PETROLEUM SMOKE. Evo, Inc., 20560 SW 115th Ave., Tualatin, OR 97062 USA Phone 503.626.1802 | Fax 503.213.5869 | www.evoamerica.com | support@evoamerica.com...
-
Page 5: Safety Label
Tualatin, Oregon 97062 USA Evo is protected under U.S Patents 6,189,530 and 6,488,022 and U.S. Patents Pending. Made in USA./ Evo est protégé par des brevets É-U 6,189,530 et 6,488,022 et brevets É-U en instance. Fabriqué aux É.-U. 10/25/2017 Evo, Inc., 20560 SW 115th Ave., Tualatin, OR 97062 USA... - Page 6 One Year from the original date of purchase from Evo, Inc. This warranty is for the benefi t of the original use purchaser and is non-transferable.
-
Page 7: Table Of Contents
SAFETY GAS PILOT LIGHT FUNCTIONALITY LIGHTING STANDING PILOT BURNERS TEMPERATURE CONTROL REMOVABLE SPILLOVER TRAYS RECOGNIZING ABNORMAL GAS OPERATION AFFINITY 30Gp DIMENSIONS COOKING SURFACE MAINTENANCE Evo, Inc., 20560 SW 115th Ave., Tualatin, OR 97062 USA Phone 503.626.1802 | Fax 503.213.5869 | www.evoamerica.com | support@evoamerica.com... -
Page 8: Unpack Cooktop Components
As you are unpacking the crate, make sure you locate all components before installation. Pilot light and ignition parts are exposed during uncrating and installation. Use caution and do not alter factory set positions. Evo, Inc., 20560 SW 115th Ave., Tualatin, OR 97062 USA Phone 503.626.1802 | Fax 503.213.5869 | www.evoamerica.com | support@evoamerica.com... -
Page 9: Clearance Dimensions
CLEARANCE FROM EDGE OF DRIP PANS. Minimum 3” clearance required under unit venting to 22 sq/in of combustible air. The minimum environmental temperature for safe use of the Evo Affi nity 30Gp ° ° should not be below 32 F ( 0... -
Page 10: Prepare Counter Top For Installation
OPENING IN COUNTERTOP FRONT Mark the fi nished position of the Evo Affi nity 30Gp drip pan on the countertop using the dimensions shown. The circular dimension of 18-1/8” is the diameter of the drip pan to the outside fl ange material thickness (located to the inside of the half-rolled bead edge). The drip pan cutout must be made precisely to these dimensions (or at a maximum +1/16”) so the half-... - Page 11 THE UNIT IF DESIRED. FRONT VIEW Construct a bay for the Evo unit with your chosen cabinet system. Position and fasten the supplied mounting brackets 7-21/32” below the fi nished countertop surface. Evo, Inc., 20560 SW 115th Ave., Tualatin, OR 97062 USA...
- Page 12 Example of 3/8” tile with substrate for a minimum 1-3/16” (3cm) overall. Make sure you allow for the countertop overhang as shown. Evo, Inc., 20560 SW 115th Ave., Tualatin, OR 97062 USA Phone 503.626.1802 | Fax 503.213.5869 | www.evoamerica.com | support@evoamerica.com...
- Page 13 (see diagrams above). A black o-ring is recessed in the top bead and designed to create a seal against the countertop. Evo, Inc., 20560 SW 115th Ave., Tualatin, OR 97062 USA Phone 503.626.1802 | Fax 503.213.5869 | www.evoamerica.com | support@evoamerica.com...
-
Page 14: Insert Chassis In Countertop
Gas Installation must be done by a licensed plumber in accordance with local guidelines once unit has been completely installed. Refer to pages 17- 18 and 21 for further instructions. Evo, Inc., 20560 SW 115th Ave., Tualatin, OR 97062 USA Phone 503.626.1802 | Fax 503.213.5869 | www.evoamerica.com | support@evoamerica.com... -
Page 15: Install Drip Pan And Drip Pan Gasket
From the inside of the skirt, use each of the three latches to pull the drip pan down into the counter. Evo, Inc., 20560 SW 115th Ave., Tualatin, OR 97062 USA Phone 503.626.1802 | Fax 503.213.5869 | www.evoamerica.com | support@evoamerica.com... - Page 16 Secure drip pan to chassis using access slot (A). Rewrap drip pan gasket around top of drip tray and secure (B). Ensure seal under drip pan edge is touching countertop(C). Evo, Inc., 20560 SW 115th Ave., Tualatin, OR 97062 USA Phone 503.626.1802 | Fax 503.213.5869 | www.evoamerica.com | support@evoamerica.com...
-
Page 17: Assembling Cook Surface Retaining Fasteners
(Ensure the Rear Retaining Bullet is placed on the right hand side of the tab). Next, loop the J-Hook through the inside slot of each remaining tab. Evo, Inc., 20560 SW 115th Ave., Tualatin, OR 97062 USA Phone 503.626.1802 | Fax 503.213.5869 | www.evoamerica.com | support@evoamerica.com... - Page 18 Place cook surface on an angle with Bullet Fastener facing down and rearward. Engage bullet fastener to keyway slot on chassis backwall and lower J-Hooks into front threaded tubes. Evo, Inc., 20560 SW 115th Ave., Tualatin, OR 97062 USA Phone 503.626.1802 | Fax 503.213.5869 | www.evoamerica.com | support@evoamerica.com...
-
Page 19: Connecting And Installing Cooking Surface
(A). Next rotate the cook surface clockwise until the support tab is in line with the seam (B) and the rear bullet is secure in the chassis slot (C). Evo, Inc., 20560 SW 115th Ave., Tualatin, OR 97062 USA Phone 503.626.1802 | Fax 503.213.5869 | www.evoamerica.com | support@evoamerica.com... -
Page 20: Installing Cooking Surface
Open both waste doors and at the rear inside corner of the enclosure, tighten 1/4” X 20 nut on end of J-Hook to retain cooking surface for burner chassis. Evo, Inc., 20560 SW 115th Ave., Tualatin, OR 97062 USA Phone 503.626.1802 | Fax 503.213.5869 | www.evoamerica.com | support@evoamerica.com... -
Page 21: Connecting Inlet Gas Line
Connect gas using 11” Water Column (Fixed) gas service. It’s recommended to have a gas shut off valve immediately off the inlet gas supply line to aid repair service of the unit. Evo, Inc., 20560 SW 115th Ave., Tualatin, OR 97062 USA Phone 503.626.1802 | Fax 503.213.5869 | www.evoamerica.com | support@evoamerica.com... -
Page 22: Safety Gas Pilot Light Functionality
Once the pilot burners are lit, it should not be necessary to relight the pilots unless the main gas supply has been shut off or has been disconnected. Evo, Inc., 20560 SW 115th Ave., Tualatin, OR 97062 USA Phone 503.626.1802 | Fax 503.213.5869 | www.evoamerica.com | support@evoamerica.com... -
Page 23: Lighting Standing Pilot Burners
STEP 4: Repeat steps 1 and 2 for the Outer Burner Pilot Light. With both the inner and outer pilot light burners lit and continuously burning, full functionality to the inner and outer main tube burners is now available. Evo, Inc., 20560 SW 115th Ave., Tualatin, OR 97062 USA Phone 503.626.1802 | Fax 503.213.5869 | www.evoamerica.com | support@evoamerica.com... -
Page 24: Temperature Control
Lo = 225F, Med = 425F, Hi = 550F (All temperatures are +- 25F. Differences in altitude and inlet gas pressure less than recommended 7”W.C for NG and 11”W.C for LP will cause a variation in set temperature). Evo, Inc., 20560 SW 115th Ave., Tualatin, OR 97062 USA Phone 503.626.1802 | Fax 503.213.5869 | www.evoamerica.com | support@evoamerica.com... -
Page 25: Removable Spillover Trays
Spillover debris and liquids can be hot and cause burns, and/or damage to the internal operation of the grill. Evo, Inc., 20560 SW 115th Ave., Tualatin, OR 97062 USA Phone 503.626.1802 | Fax 503.213.5869 | www.evoamerica.com | support@evoamerica.com... -
Page 26: Recognizing Abnormal Gas Operation
Evo, Inc., 20560 SW 115th Ave., Tualatin, OR 97062 USA Phone 503.626.1802 | Fax 503.213.5869 | www.evoamerica.com | support@evoamerica.com... -
Page 27: Affinity 30Gp Dimensions
A f f i n i t y 3 0 G p AFFINITY 30Gp DIMENSIONS 30” 762mm Diameter 36 5/32” 914mm 11-7/32” 292mm Evo, Inc., 20560 SW 115th Ave., Tualatin, OR 97062 USA Phone 503.626.1802 | Fax 503.213.5869 | www.evoamerica.com | support@evoamerica.com... -
Page 28: Cooking Surface Maintenance
To condition the Evo cook surface you should use the grill cleaning kit supplied with your grill. The grill cleaning kit contains a blue grill pad handle, grill cleaning screens, and grill grey polishing pads. Use the polishing pad after the grill cleaning pads to achieve a smooth cooking surface for the most delicate foods and applications.
