Powerware Ferrups FE/QFE 500VA Installation Manual page 43

60 Hz 208 Vac or 240 Vac Input - 120/208 Vac or 120/240 Vac Output
For 208 Vac, use only a BBM switch.
Figure 9. FE 500 VA–3.1 kVA UPS with External Bypass Switch
Table 14. Minimum Recommended Circuit Breakers for 208 Vac or 240 Vac
Charger 500 VA –1.4 kVA
Standard 15
15A 15
Powerware ® FERRUPS FE/QFE UPS (500 VA–18 kVA) Installation Guide
208 Vac
1.8 kVA 2.1 kVA 3.1 kVA
15 15 20
20 25 30
:
External Bypass Switch Installation
240 Vac
500 VA –1.4 kVA 1.8 kVA
15 15
15 20
Rev A www.powerware.com
2.1 kVA 3.1 kVA
15 15
20 25
37
