3.6 Peak Hold Traces:
Up to four traces, each, which traces the Peak Power in the Live Sweep waveform, can be set.
However, only one of these four traces can be active at a given time. An active trace can be frozen by
clicking the "Freeze" button for further analysis. If a peak trace is frozen, a new trace can be
activated by clicking the corresponding check box, without disabling the frozen trace. Clicking
"Hide" check box can hide the traces. Fig 4 shows the Peak traces in detail.
Fig 16 Peak Traces
22
