2.6 Record/ Log Spectrum:
Once in the Spectrum Mode or the Trigger Spectrum Mode, the Spectrum Data being viewed on
the Screen may be logged by clicking this button. The Logged File is saved with the spl extension.
2.7 Replay the Logged Spectrum for post-processing/analysis:
This button selects BumbleBee Tablet Log Files (with extension spl) and replays them for post-
processing and analysis. Once the playback begins, this button changes in appearance to
this changed button freezes the playback and the button becomes
button again to resume normal playback.
2.8 Stop Recording/Playback:
Stop the current recording or playback.
2.9 Fast Forward:
The replay speed is doubled. Click this button again to resume normal playback.
2.10 Rewind:
The play back is reversed at doubled speed. Click this button again to resume normal playback.
NOTE: For detailed explanation on Logging and re-playing a Spectrum Log File, see page29
2.11 Print Preview & Print.
This prints out the current Spectrum Display. The Display can be printed out either in True Color:
A true snapshot of the Display screen is printed as seen on the Display (with the Black Background); or in
Econo Color: A snapshot of the Display is taken and printed against a white background or in Black and
White: A Black and White print out is taken (i.e. Black foreground against a white background). The
options can be changed in the File menu by Clicking on "Print Color Options". Once clicked, the
following Dialog Box pops up. Then select the option of choice and then click OK and click
preview of the screen.
Fig 3: Print Color Selection Options Dialog
in appearance again. Click this
