7. If the Marker/Delta have been positioned on the Peak Hold Trace or the Average Trace, the
markers will shift on the Active Spectrum Trace the moment the Peak Hold or the Average Trace
is disabled.
8. Click to position the markers on the Peak value of the trace on which they have been set.
9. Click
been set.
10. Click to shift the Marker/Delta to the left and click
right of the trace on which they have been set.
Fig 15.1: Marker/Delta Marker
Fig 15.2 shows the measurements between the Maker and the Delta. The
MHz apart with the Delta being 6 dB above the Marker. The Channel Power between the Marker and the
Delta marker is –58.62 dBm. Similarly the
Delta being 41 dB below the Marker. The Channel Power between them is –105.33 dBm.
to position the markers on the Center Frequency of the trace on which they have
Fig 15.2. Marker/Delta Info
Blue Marker/Delta marker pair is 15.35 MHz apart, with the
21
to shift the Marker/Delta on the
Red Marker/Delta pair is 2.51
