Connection and Installation

- Connect your DVD, VCD, V8 or TV Game to the S-Video or Composite-Video Input
port (2 or 3 on the front panel).
- Connect your monitor to the VGA Output port (Number 2 on the side panel).
- Connect your VGA Card to the VGA Input port (Number 1 on the side panel).
- Connect your speakers to the Audio Output port (Number 1 on the rear panel).
- Connect your DVD, VCD, V8 or TV Game to the Audio Input ports- R and L
(Number 2 on the rear panel).
- Connect your sound card to the Line Input port (Number 3 on the rear panel).
- Connect you power supply to the DC Input port (number 2 on the front panel).
- Once all connections are complete turn the unit on (Using the top panel push button).
- The top panel push buttons and the OSD menu will allow the user to adjust the level
of parameters to the desired level.

Specifications

Input
Output
Power
Accessory
Please browse our online catalogue to view our full product range.
44-48 Maitland Road, Mayfield East, NSW, 2304 Australia,
S-Video
Composite Video- RCA cable
Audio Input (R + L)- Stereo Audio cable
VGA Input- VGA cable
Audio Output
VGA Output- VGA 15-pin connector cable
DC
Remote control included in kit
