Operation Controls and Function

Front Panel

1. DC-In- This is the power supply input port. Connect it to the power adapter.
2. S-Video In- This is the S-Video Input port.
3. Composite Video In- This is the Composite Video Input port. Connect this port to
your DVD, VCD, V8, X-Box or PS2.

Side Panel

1. VGA-In- This is the VGA Input Port. Use the VGA cable to connect the port to your
PC.
2. Monitor (VGA-Out) - This is the VGA Output Port. Using the 15-pin connector
connect the port to your monitor.
