Summary of Contents for Magnimage LED-500CD
- Page 1 LED Video Processor User manual △ Before using this LED video processor,please read this manual carefully and preserve it for reference in the future. carefully MAGNIMAGE LED-500C...
- Page 2 Statements Without the written permission, any unit or individual could not copy, reproduction or translate the book or part of it. Also could not transmit it in any form or any way (electronic, mechanical, photocopying, record or other way) for any business and profitable purpose. The product specifications and information mentioned in this manual is just for reference, will not give prior notice if there is any updated.
-
Page 3: Table Of Contents
Directory BRIEFS · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 3 ·... - Page 4 WARRANTY · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · 38 GRAPHIC CATALOG：...
-
Page 5: Briefs
Briefs Thanks for your purchasing our LED Video processor. Do hope you can enjoy the experience of the product performance. The design of the LED video processor conforms to international and industry standards. But if with improper operation, there will be a personal injury and property damage. In order to avoid the dangerous, please obey the relevant instructions when you install and operate the product. -
Page 6: Features
Features Support ultrahigh resolution output 、 ultrahigh horizontal frequency resolution. Quick switching for input of single machine. Realize switcher’s function by multi-machine connection,support cut and fade function for multi-inputs . Picture and text overlay, cutout composite function, convenience to ... -
Page 7: Using Directions
Using directions Included Accessories User manual Power line CVBS cable ╳ 1 DVIsignal line Certificate of M3 screws ╳ 4 quality Sending card stud bolts ╳ 4 RS232 series port line╳ 1... -
Page 8: Extended Port
Extended Port Port Model Explanation Extend DVI port LED-500CD Add another DVI input Extend SDI port LED-500CS Add another SDI input / loop port Extend VGA port LED-500CV Add another VGA input Safety instructions Please use the correct power supply according that the power input ... -
Page 9: Function Introduction
Function introduction Brief LED-500 series products are the video processor developed for the large screen display system, adopted the top image processing chips , internal 12 bits processing, with clearer images and richer colors. Advanced alternate motion picture processing technology, to remove video motion tail or jagged, for the normal PAL/NTSC video, output image will be clearer, for the HD 1080i signal, output image details will be rich, full color and image quality is in the leading level. -
Page 12: Technical Specification
Technical Specification Inputs Ports quantity Rresolution PAL/NTSC/SECAM VESA 1+1（inherent 1，extend 1） VESA HDMI EIA/CEA-861,meet HDMI-1.3 standard 1（EM） 480i、576i、720p、1080i/p（3G SDI） Outputs Ports quantity resolution 1024×768/60Hz/75Hz/85Hz/100Hz/120Hz 1280×1024/60Hz 1440×900/60Hz 1600×1200/60Hz 1600×1200/60Hz– Reduced 1680×1050/60Hz 1920×1080/60Hz/50Hz 2560×816/60Hz 2048×640/60Hz 1920×1200/60Hz 2304×1152/60Hz 2048×1152/60Hz 1024×1280/60Hz 1536×1536/60Hz SDI loop 480i、576i、720p、1080i/p（3G SDI）... -
Page 13: Using The Menu
Using the menu Using the menu system can set to this machine convenient and intuitive to meet the demands of user. LED-500C using a highlight and high contrast LCD screen to display the whole user menu. When the user does not operate or operate in overtime, the LCD screen will display a non-menu state. - Page 14 Above the figure, there are 4 lines content, explanation as the following: Lines Details Channel 1 (main channel, is also default channel) port name and current The first line input signal resolution. The second line Channel 2 (vice-channel) port name and current input signal resolution. State prompt area, by several icons to show the machine current working state.
-
Page 15: Form 1 ：State Icons And Meaning
In the non-menu state, the third line area of LCD screen is status prompt area, by several icons to show the machine current working status. Please see the table below: Form1：State icons and meanings Icons Area Name Hint（shortcut key in the bracket） Synchronism When the splicing function is in opening state, follow-up... -
Page 16: Main Menu Introduction
Main menu introduction The main menu will show the symbols listed in the table below, please check its specific meaning : Symbols Explanation >> Press“RIGHT”or“OK”to enter detailed setup interface，or operate directly ▼ After this ,there is another more page ,to enter next page ,press “DOWN” on the last item ▲... -
Page 17: Main Menu
Main menu In the MENU state, press“MENU”button, the MENU system will enter the main MENU state, the LCD screen will show the details as below: Picture >> Output Setting >> Function >> Video Crop >> ▼ Zoom >> ▲ Dual Pictures >>... -
Page 18: Picture Sub Menu
Picture sub menu Picture Mode Normal Brightness Contrast Color ▼ Sharpness ▲ 3DNR /VGA Flicker Scheme Normal DVI Enhance ▼ Color Tempture Normal Black Stretch ▲ Color Temperature >> Green Gamma Blue Picture MOde Divided into “Normal”、“Soft”、“Vivid”、“User” the four options. Brightness Range 0~100. -
Page 19: Output Setting Sub Menu
Output setting sub menu Output Resolution >> Output To H Window 1024 V Window 1024×768 60Hz Step ▼ Press L&R To Sel H Position ▲ Press OK To Conf V Position Part Or Full Full Output LED-500C support 19 kinds of output Resolution, maximum width 2560, and maximum height 1536. -
Page 20: Function Sub Menu
Function sub menu Language English Save Seemless Switch Template 1 Freeze Press OK to Confirm OSD Timer ▼ Save Template >> ▲ Restore Restore Template >> Template 1 Volume Press OK To Confirm Mute ▼ Factory Reset Factory Reset >> ▲... -
Page 21: Video Crop Sub Menu
Video Crop sub Menu H start V start Video Crop Width 1920 Setting >> Height 1080 Step Coarse Reset >> Video Crop Reset Press OK To Conf Menu To Cancel Video Crop Image cropping function for input signal“On”or“Off”. Default is Off. Setting H start：the minimum value is 0, the maximum value is the D-value of“input signal width”minus“64”. -
Page 22: Zoom Sub Menu
Zoom sub Menu Zoom H Pan H Zoom Level 100% V Pan V Zoom Level 100% >> ▼ Reset >> ▲ Zoom Reset Press OK To Conf MENU To Cancel Zoom Zoom function“On”and“Off”. The default is Off. H zoom level In percentage form to enlarge the image in horizontal direction, step length 5%, maximum is 1000%, and the minimum is 100%. -
Page 23: Dual Pictures Sub Menu
Dual Pictures sub Menu Text Overlay Dual Pictures Source Blend Mode Mode1 Step Above/Below Above H Window 1024 ▼ And/Or ▼ V Window ▲ Text Overlay ▲ H Position V Position Green Transparent ▼ Blue Text Overlay >> ▲ VGA1 <- 【OK】... - Page 24 resolution window”. V Position The top-left corner of Vice channel image vertical coordinates in“output resolution window”. Transparent The transparency of vice channel image, range is 0~3, when the value is 0, completely opaque, 3 the transparency is the highest. Text Overlay Text overlay, cutout synthesis menu, check details in the text overlay specification[...
- Page 25 Note 2: During switch input port, the system to channel 1 for priority, if channel 2 port and channel 1 port conflict with each other, port 2 will be switched under the port 1 automatically. Text Overlay Text Overlay Text overlay function“open”and“closed”. The default is closed. Blend Mode Divided into“mode 1”and“mode 2”two patterns.
- Page 26 Fade In&Out Switch Fade In&Out “ VGA1 ╳ <- 【OK】 -> DVI”, as shown in the left example, “【OK】” Switch the left side shows the name of the input port of channel 1, channel 2 on the right shows the input port name; sample The cursor is on the left, the port name is VGA1, next to the“╳”that no valid signal under VGA1 input port;...
- Page 27 Multi-machine connection instruction Multi “ VGA2 <- 【OK】 -> ╳ ”, as shown in the left example, the cursor machine is located in channel 2, port name is DVI, next to the“╳”that no valid signal Fade In&Out under DVI input port; when the cursor is located in the channel 2 (The Switch cursor on the right), use the“input port selection key”to switch the input port of channel 1.
-
Page 28: Mosaic Sub Menu
Mosaic sub Menu Mosaic Option Unequal Mosaic Equal >> H Total 1536 Unequal >> V Total H Start ▼ Equal Mosaic V Start ▲ Position Width H Units Height V Units Step The Equal Mosaic function“On”or“Off”, default is off. Equal Equal Mosaic Position Choose the current video processor display position in the whole... -
Page 29: Shortcuts Menu
Shortcuts menu LED-500C sets up total nine input shortcuts and six function shortcut keys. Input shortcuts are: “AV1”,“AV2”,“VGA1”,“VGA2”,“DVI”，“HDMI”and“E.M.”respectively; Function shortcuts are:“PIP”,“CROP”,“PART”,“AUTO”,“MODE”and“FADE”. All the name of the keys and its position of the machine, please refer to the "Front panel graphical representation"... - Page 30 Function shortcuts PIP function shortcuts： The shortcuts only can be available in“seamless switching”function closed. If in the PIP open state, “ seamless switching” function open, then PIP function will be forced to close. Icon Explanation PIP function closed, channel 1 signal display normally. PIP function open, channel 1 is on top, namely channel 1 display area covers channel 2 image.
- Page 31 AUTO function shortcuts： In the “non-menu state” [ 11], press “AUTO” button, the menu system will display the following tips： Auto Adjusting Please Wait . . . At this moment, system is to adjust the display position of the image automatically, after this process completed, the menu system returns to“non-menu state”[...
- Page 32 FADE function shortcuts： the“non-menu state”[ 11], press“FADE”button, the menu system will enter the fade in fade out switching state as below： VGA1 <- 【OK】 -> DVI Fade Period Multi Connection >> Reset >> ▼ Tips： 1、In the shortcut menu, you can switch input port for the bottom layer, but it is not safe behavior, because in the absence of pre-monitoring situation, you can not accurately grasp the switching time.
-
Page 33: Using Mosaic
Using Mosaic Mosaic summarize LED-500C single has two send card slots, two cards can convey the same image for the two LED display at the same time, also can use two cards cascading, and increase the load area for conveying HD image to a high resolution LED display. If the actual pixel of the LED display beyond of the sending cards loading ability, for this kind of circumstance, need to use more than one sending cards and use video processor splicing function to solve. -
Page 34: Equal Mosaic
Equal Mosaic Equal Mosaic can be applied to the circumstances of the each group LED splicing unit parameters are the same. For example：there are 6 groups of identical LED screen, each group has a card or a group of cascade of sending cards to carry image, now will give this six groups screen spliced a screen to display according to the 3 level groups, 2 vertical groups as below：... -
Page 35: Unequal Mosaic
Following is the system diagram： LED-500C LED-500 C LED-500C LED-500C LED-500C LED-500C DVI splitter LED-500C Unequal Mosaic Unequal Mosaic is applicable to all need splicing occasions, equal splicing is the special case of the unequal splicing, namely is the special situation of all splicing unit parameters are the same. - Page 36 Processor No. 1 No. 2 No. 3 No. 4 Parameter H Total V Total H Start V Start Width Height After finished the system constructing, need to test the splicing effect, if "synchronous follow-up" function cannot be successfully launched (namely synchronous follow-up icon are not displayed for a long time), then need to add a LED-500 to do signal shaping, and the above four sets LED can share the plastic signal by DVI splitter output.
-
Page 37: Input Signal Hot Backup
Input signal hot backup Summarize Note that what the input signal warm backup is? What is the use of it? In simple terms, warm backup is that when the input signal missed, using spare input signal automatically and rapidly to replace the original input signal, maximum ensure output image uninterrupted. - Page 38 How to use the hot backup? Enter the“PIP submenu”and select“automatic switching function”, you can set how to use LED-500C hot backup function here. Here are four options, for details please refer to the table below： Item Details Not to use the heat backup function If channel 1 signal is effective, then output channel 1 image, Window1 otherwise, the output channel 2 image.
-
Page 39: Faq
LED-500C provides abundant function for the customers, some functions use requires users to have quite a bit of professional knowledge. When you have problems, can try to timing machines, if cannot solve it according the following step, please contact with the local agent, or contact our service department directly. -
Page 40: Model Introduction
Model introduction LED-500CX SDI input/loop out Expand external DVI input port Expand external VGA input port Warranty The whole unit warranty One year (from the buying date); If the invoice is lost, the 60 days after the production date will be the warranty start date ...
