- Page 1 LED-F904 LED Video control ser ver Instructions for User, V1.1 △ Before using the LED video control server, please read the instruction manual carefully and keep it properly for future reference.
- Page 2 statement Without the written permission of the Company, no unit or individual shall copy, copy, copy or translate part or all of the contents of this manual. This manual shall not be disseminated in any form or in any means (electronic, mechanical, photocopied, recorded,...
-
Page 3: Table Of Contents
catalogue Brief introduction .........................1 brand royalty ...............................1 About software ..............................1 product features ..............................2 Port extension ..............................3 safety instruction ............................... 3 Function Introduction ......................... 4 summary ................................4 technical specifications ............................7 Use the menu ..........................9 How to use keys ..............................9 MENU : ................................9 LAYER : ................................ - Page 4 preset: ................................. 24 Clear all preset: ............................24 Communication Settings: ........................25 Fiber output settings: ..........................25 work mode: ............................... 26 Output Freeze: ............................26 Language / English: ..........................27 Time task management: ........................27 Key lock: ..............................28 label: ................................28 Synchronous Lock Settings: ........................ 28 Version information: ..........................
-
Page 5: Brief Introduction
Brief introduction Thank you for purchasing our LED video control server. I hope you can experience the excellent performance of the product. The LED video control server is designed to comply with international, industry standards, but it can still cause personal injury and property damage. To avoid the potential hazards and benefit from your equipment whenever possible, follow the relevant instructions in this manual when installing and operating the product. -
Page 6: Product Features
width is 8192 pixels and max height is 3840 pixels Support for template saving and retrieving Support for connecting the MAGNIMAGE C-Link series receiving cards Support receiving card serial number calibration, switch on the intelligent serial number to visually check the position of the cabinet Support network port communication, set up multiple area network ... -
Page 7: Port Extension
Corresponding Basic model modules product model Extend the external 1-sheet SDI input LED-F904 LED-F904S module safety instruction The input voltage range of the power supply of this product is 100~240V, and 50 / 60Hz. Please use the correct power supply. -
Page 8: Function Introduction
LED screen transmission card functions by MAGNIMAGE. This series integrates various professional input interfaces, support up to 4K x 2K / 60Hz, LED-F904 with 8..80 million pixels, support 8 gigabit port output; can be used with the company’s Mach series receiving card. -
Page 11: Technical Specifications
Technical specifications Input Specifications Number of port Resolution specifications ports Maximum resolution: 3840 x 1080 / 60Hz, downward compatibility Support for EDID management Maximum resolution: 3840 x 1080 / 60Hz, downward compatibility DP 1.1 Support for EDID management Custom resolution, MAX width 3840 pixels,MAX height 2160 pixels Maximum resolution: 3840 x 2160 / 60Hz, downward... -
Page 12: Control Interface
control interface Network port Two RJ45 control ports, with connected upper computer or communication multi-stage cascade communication port Square port communication Used to connect the upper computer computer port The RS232 port Used for central control Complete machine specification Enter power 100-240V AC~50/60Hz 0.6A supply... -
Page 13: Use The Menu
Use the menu The menu system using the product can be convenient and intuitive to set the local machine to meet the users requirements. The video control server uses a full-color LCD screen to display the entire user menu. When the user has no operation or the operation timeout. If the keys in the front panel of the machine are used to set the machine, the LCD screen will display the corresponding menu according to the user's operation to prompt the user to conduct better, faster and more intuitive... -
Page 14: Layer
In the main menu, the confirmation key is also used to switch between the browse and set modes, for example: Browse mode Set the mode ↖ Confirm button, tap the “knob”to switch ↗ between the above two modes In browse mode, rotate the knob counterclockwise with the cursor moving upward or left;... -
Page 15: Default Status Introduction
the input button in INPUT area. The currently selected one is in red. Default status introduction After turning on the power of the video control server, the LCD screen on the front panel. After the startup, the default state of the current machine, demonstrated by LED-F903S, as shown in the figure below: LED-F903S: The information in the figure above is described below:... -
Page 16: Main Menu Introduction
Rotate the button clockwise in the default state: You can clearly see the signal source corresponding to the layer and the resolution of the signal source Continue to rotate the knob clockwise to see the following below: You can clearly see the input state and the input resolution of all the signal sources Main menu introduction In the main menu, the user uses the"... -
Page 17: Primary Menu
Execute Use the knob to select the item and press the knob button function Return to the press" "key superior menu Confirm In order to avoid misoperation, the "knob" key is used to confirm the operation operation primary menu In the default state, press the "knob" button, the menu system will enter the main menu state, as shown below on the LCD screen: There are 4 menu items in the main menu. -
Page 18: Screen Configuration
Screen configuration Screen brightness: Output resolution: Quick configuration:... -
Page 19: Manual Configuration
Manual configuration: CabineMark: Screen You can debug the large screen brightness (default is 50, brightness brightness range 0~256) Output Customize the output resolution of the setup device resolution The display should be regular, non-alien, and the box size and resolution When the width and height of the box, the cable routing mode is the Quick same, and the serial number of the network port is connected in turn,... -
Page 20: Rx Card Reset
Description: The internal quick configuration and manual configuration function do not support free routing and automatic empty function CabineMark (MAPPING) diagram: Description: The number in the upper left corner is the network port number, and the middle number is the box number Rx card reset: Tx card reset:... -
Page 21: Test Pattern
Test Pattern: Test drawing card 1~10 Reset the reception card brightness, color temperature, Gamma and Rx card reset other parameters Tx card reset Reset the sending card connecting screen parameters Test pattern The default is off state, supporting 10 map card test screens Test Drawing card style: Ethport backup:... -
Page 22: Parameter File
Multi-machine backup: Param file: This function is not available, the device is mainly Local backup fixed network port 1-3, network port 4-6 for backup Ethport When multiple machines are in the same LAN, you backup Multi-machine can choose another device as backup or mainly, and backup set another IP address to achieve fast backup Bandwidth... -
Page 23: Linup File
(form:DTR) disk parameters Save the U-disk screen parameters to the machine Save to local U-disk files Get all the screen parameter files in the U disk Local para save Save the screen parameters to the machine Local parameters U disk that save the parameter files stored in the Save to U disk machine Obtain all single box parameter files stored in the... -
Page 24: Layer Settings
Note: The function of single box parameter file and screen file should be inserted into U disk in the USB interface of the device, and the USB can be switched to U disk file in the communication Settings. If the U disk is not inserted or the USB communication to U disk file is modified, some functions are not available in gray. - Page 25 Each layer can be intercepted independently without affecting each other, and this intercept is the signal source intercept of the layer horizontal The maximum value is the difference of Horizontal Width minus Horizontal Width position Vertical The minimum value is 0, and the maximum value is the position difference of Vertical Height minus Vertical Width.
-
Page 26: Picture
Picture: luminance Range 0-100, with a default value of 50 contrast Range 0-100, with a default value of 50 ratio 4000K, 5000K, 6500K, 7500K, 8200K, 9300K, 10000K, 11500K, colour picture temperature user and other 9 modes Return the brightness, contrast, and color temperature reset parameters set by the user to the factory default value Color temperature effect:... -
Page 27: Input Settings
Input settings EDID setting: RGB Range: EDID select Support DVI, HDMI, and DP input EDID management H_ Active Custom horizontal width V_ Active Custom vertical height Custom refresh rate, refresh rate range: 23-241Hz advanced Adjust the input H and V Black parameters and select Apply to take... -
Page 28: Misc. Settings
setting effect The color range of DVI, HDMI and DP input can be modified into RGB range "automatic", "0-255" and "16-235" Note: After setting the EDID, different computers, different graphics card output, may need to restart the computer or unplug the signal line, in the computer display Settings menu, select the corresponding resolution. -
Page 29: Communication Settings
Communication Settings: USB setting : Machine LCD panel display Fiber output settings: You can change the native IP address position Switch to this mode, you can use the square Communication communi port USB communication Settings cation U disk file Switch to this mode, you can upgrade the... -
Page 30: Work Mode
machine using the flat port USB Support "optical port hot backup" and "optical port copy output" two Fibre Output optical port working mode, the default is optical port copy output Settings mode. Diagram of optical port replication connection: Note: The front-end device can be used as a control, through the optical port transmission to the same device or the device photoelectric conversion box OPT 10, and then control the LED display screen, open layer, switch input source, etc Work mode:... -
Page 31: Language / English
Language / English: Time task management: Support the "two-in-one" and "photoelectric" two working modes, the work mode default for the two-in-one mode. output freeze Freeze the current frame of the device output screen Language You can switch to English or simplified Chinese style Language Time Set the time and date of the machine itself... -
Page 32: Key Lock
select a trigger time, and then select the trigger time point screen brightness or load the preset, task operation: "once", "everyday", "period". For example, when task 1 is daily at 18:00:00, the screen brightness is adjusted to 128, the time is set to 18:00:00, the brightness is set "128", the task operation is set to "everyday", and then return to the running schedule, and task 1 will show yellow... -
Page 33: Synchronous Lock Settings
Synchronous Lock Settings: Device key lock, default "off" status; open the key lock and unlock the Key lock password is "1234" It is convenient to mark which areas the machine carries, and you can define the serial label number for the machine. The function can be displayed on the LCD screen of the machine. -
Page 34: Factory Reset
Factory reset: Version Check the ARM, FPGA, CPLD version and the current operating temperature of the machine information Electrical Display the current operating temperature of the machine status Caption It can save 3 subtitles, and the subtitle text, font color, background color should be set in the upper computer software function Restore all the user settings to the factory status... -
Page 35: Warranty Instructions
Warranty instructions Complete machine warranty period 12 months from the date of the users purchase invoice; If the user purchase invoice is lost, the 60 days after the production date of this product is the warranty start date for that product. Non-warranty provisions Fault or damage caused by other abnormal use reasons, such as ...
