- Page 1 LED Video processor User manual △ Before using this LED Video processor, please read this manual carefully and preserved for reference in the future. MAGNIMAGE LED-540...
- Page 2 Statements Without the written permission, any unit or individual could not copy, reproduction or translate the book or part of it. Also could not transmit it in any form or any way（electronic, mechanical, photocopying, record or other way) for any business and profitable purpose. The product specifications and information mentioned in this manual is just for reference, will not give prior notice if there is any updated.
-
Page 3: Table Of Contents
Directory BRIEFS ················································································································· 3 ·································································································· 3 RADEMARK CREDIT ···································································································· 3 BOUT SOFTWARE ················································································································ 4 EATURES USING DIRECTIONS ····························································································· 5 ····························································································· 5 NCLUDED CCESSORIES ······································································································· 6 XTENDED ······························································································· 6 AFETY INSTRUCTIONS FUNCTION INTRODUCTION ················································································· 8 ····················································································································· 8 RIEF ······································································ 9 EAR PANEL GRAPHICAL REPRESENTATION ··································································... - Page 4 ··············································································· 41 ULTI MACHINE LOAD TEMPLATE ············································································ 42 ULTI MACHINE FADE IN FADE OUT INPUT SIGNAL HOT BACKUP ·············································································· 43 FAQ ··················································································································· 45 MODEL INTRODUCTION ···················································································· 47 WARRANTY ······································································································· 47 GRAPHIC CATALOGUE: 1：S ..............14 TATE ICONS AND MEANINGS 2：D ........
-
Page 5: Briefs
Briefs Thanks for your purchasing our LED Video processor. Do hope you can enjoy the experience of the product performance. The design of the LED video processor conforms to international and industry standards. but if with improper operation, there will be a personal injury and property damage . In order to avoid the dangerous, please obey the relevant instructions when you install and operate the product. -
Page 6: Features
Features Support ultra-high output resolution and ultra-high horizontal frequency resolution. To switch the Stand-alone signal input channel rapidly. Many machines' connection to achieve the function of switch and the prompt switch between multiple signals input channel. Picture and text overlay, cutout composite function, convenience to ... -
Page 7: Using Directions
Using directions Included Accessories Using manual Power line CVBS cable ╳ 2 DVI signal cable USB cable Disk M3 screws ╳ 4 3.5 mm Stereo Certificate of headphone line quality Sending card stud bolts 4pin2.54 sending card power cable... -
Page 8: Extended Port
Extended Port Port Model Explanation Extended DVI Port LED-540CD Add another DVI input port Extended HDMI Port LED-540CH Add another HDMI input port Extended SDI Port LED-540CS Add another SDI input/loop port Extended VGA Port LED-540CV Add another VGA input port Safety instructions Please use the correct power supply according that the power input ... - Page 9 The product is the electronic product; please stay away from the fire, water and of which is inflammable and blast, dangerous. This product is with high pressure components, please don't open the case or maintain it by your own. As there is exceptional condition with smoke, ill-smelling, please turn off ...
-
Page 10: Function Introduction
Function introduction Brief LED-540 series products are the video processor developed for the large screen display system, adopted the top image processing chips , internal 12 bits processing, with clearer images and richer colors. Advanced alternate motion picture processing technology, to remove video... -
Page 13: Technical Specification
Technical Specification Input indicators Port Number Resolution PAL/NTSC VESA standard VESA standard (support 1080i) （inherent 1 way,scalable 1way） HDMI EIA/CEA-861， HDMI-1.3 1 (E.M.) 480i、576i、720p、1080i/p (3G SDI) Output indicators Port Number Resolution in accordance with DVI input, not to support HDCP looping out DVI input looping out 1024×768/60Hz/75Hz/85Hz/100Hz/120Hz 1280×1024/60Hz... -
Page 14: Using The Menus
Non-menu state introduction Turn on the power supply of LED-540, in the process of the system startup, the LCD front panel would display the start interface on the left screen, when the start completed, there will show the machine’s current state on the screen as... - Page 15 Above the figure, there are 4 lines content, explanation as the following: Lines Details Channel 1 (main channel, is also default channel) port name and current The first line input signal resolution. The second line Channel 2 (vice-channel) port name and current input signal resolution. State prompt area, by several icons to show the machine current working state.
- Page 16 Form1：State icons and meanings Icons Area Name Hint（shortcut key in the bracket） Synchronism When the splicing function is in opening state, follow-up state Synchronism follow-up is also started successfully area Equal splicing Equal splicing function is Enable state Unequal splicing Unequal splicing function is open state PIP off...
-
Page 17: Main Menu Introduction
Main menu introduction The main menu will show the symbols listed in the table below, please check its specific meaning in the table below: Symbols Explanation >> Press “RIGHT” or“OK”to enter the detail setting page, or operate that directly. ▼ The next page is after this page, press“DOWN”button in the last item of this page to enter the next page ▲... -
Page 18: Main Menu
Main menu In the MENU state, press “MENU” button, the MENU system will enter the main MENU state, the LCD screen will show the details as below: Picture >> Output Setting >> Function >> Video Crop >> ▼ Zoom >> ▲... -
Page 19: Picture Sub Menu
Picture sub menu Picture Mode Normal Brightness Contrast Color ▼ Sharpness ▲ 3DNR /VGA Flicker Scheme Normal DVI Enhance ▼ Color Tempture Normal Black Stretch ▲ Green Color Temperature >> Blue Gamma Picture MOde Divided into “Normal” 、 “Soft” 、 “Vivid” 、 “User” the four options. Brightness Range 0~100. -
Page 20: Output Setting Sub Menu
LED screen. If do not have suitable output resolution, please select the options with bigger resolution than the screen’s. For example, there is a LED screen whose physical resolution is 1152╳960, you cannot find the resolution in the output resolution lists of LED-540, and larger... - Page 21 and nearest resolution is “1280╳1024 60Hz” , in such circumstances, please set the output resolution to be “1280╳1024 60Hz” . In addition, still need to set the H Window to be the practical width of the LED screen, 1152. And the V Window should be the practical vertical height, 960.
-
Page 22: Function Sub Menu
▲ Factory Reset Press OK To Conf Press Mu to Rtn Language Display language of LED-540 menu system，have“中文”and“English”two options. Seemless Off：Seamless switch function closed, in the process of switching input signal Switch port, black screen first, and then open the new input signal port. - Page 23 LED-540 supports multi-machine to cascade, in the cascade condition, the machine provides a quick recovery multi-machine template function, namely shortcuts "MODE". In the cascade state, to press "MODE" button from any one of the front panel LED-540s, all LED-540s will enter into a unified restore template interface, and then use the ten numeric keys of the front panel, can rapid recovery multi-machine template.
-
Page 24: Video Crop Sub Menu
Video Crop sub Menu Video Crop H start Setting >> V start Step Coarse Width 1920 Reset >> Height 1080 Video Crop Reset Press OK To Conf Menu To Cancel Video Crop Image cropping function for input signal“On”or“Off”. Default is Off. Setting H start：the minimum value is 0, the maximum value is the D-value of“input signal width”minus“64”. - Page 25 Additional remarks: input signal width, height and other information can be checked in the display of “ current input signal resolution specifications” and in the state of“non-menu state”[ 12]. For example, input signal resolution specifications of signal input channel 1 is 1920 ╳...
-
Page 26: Zoom Sub Menu
Zoom sub Menu Zoom H Pan H Zoom Level 100% V Pan V Zoom Level 100% >> ▼ Reset >> ▲ Zoom Reset Press OK To Conf MENU To Cancel Zoom Zoom function“On”and“Off”. The default is Off. H zoom level In percentage form to enlarge the image in horizontal direction, step length 5%, maximum is 1000%, and the minimum is 100%. -
Page 27: Dual Pictures Sub Menu
Dual Pictures sub Menu Text Overlay Dual Pictures Blend Mode Mode1 Source Above/Below Above Step And/Or ▼ H Window 1024 ▼ Text Overlay ▲ V Window ▲ H Position Green V Position Blue Transparent ▼ Text Overlay >> ▲ VGA1 <- 【OK】... - Page 28 V Position The top-left corner of Vice channel image vertical coordinates in“output resolution window”. Transparent The transparency of vice channel image, range is 0~3, when the value is 0, completely opaque, 3 the transparency is the highest. Text Overlay Text overlay, cutout synthesis menu, check details in the text overlay specification[ 27].
- Page 29 Note 2: During switch input port, the system to channel 1 for priority, if channel 2 port and channel 1 port conflict with each other, port 2 will be switched under the port 1 automatically. Text Overlay Text Overlay Text overlay function“open”and“closed”. The default is closed. Blend Mode Divided into“mode 1”and“mode 2”two patterns.
- Page 30 Fade In&Out Switch Fade In&Out “ VGA1 ╳ <- 【 OK 】 -> DVI ” , as shown in the left example, Switch “ 【OK】 ”the left side shows the name of the input port of channel 1, channel 2 on the right shows the input port name; sample The cursor is on the left, the port name is VGA1, next to the“╳”that no valid signal under VGA1 input port;...
- Page 31 Multi-machine connection instruction Multi “ VGA2 <- 【OK】 -> ╳ ” , as shown in the left example, the cursor is machine located in channel 2, port name is DVI, next to the“╳”that no valid signal Fade In&Out under DVI input port; when the cursor is located in the channel 2 (The Switch cursor on the right), use the“input port selection key”to switch the input port of channel 1.
-
Page 32: Mosaic Sub Menu
Mosaic sub Menu Unequal Mosaic Mosaic Option H Total 1536 Equal >> V Total Unequal >> H Start ▼ V Start ▲ Equal Mosaic Width Position Height H Units Step V Units Equal Equal Mosaic The Equal Mosaic function“On”or“Off”, default is off. Position Choose the current video processor display position in the whole splicing image, range is 1~64. -
Page 33: Shortcuts Menu
Additional remarks: in "seamless switching” function open state, press any input shortcuts, the system will be preparation for signal and automatic switching in the next around 1 seconds time, the whole switching will delay about 1 second, at that time, the LED-540 menu system will display waiting for... - Page 34 information, as below: Source Switching Please Wait . . . When the seamless switching completed, the menu system will be into "non-menu state" automatically [ 12]. If users need to switch Channel 2 signal input port, please enter“PIP submenu”, and adjust“input source”option. Function shortcuts PIP function shortcuts：...
- Page 35 PART function shortcuts： PART function, namely PART or full-screen display image fast switching function. In the state of LED display normally, PART function should be closed; When in the circumstance of the monitor to setup broadcast, can use PART function open, image full resolution display characteristics, to make the process convenient and fast.
- Page 36 For example： Num. Key To Load Templates In the multi-machine connection state, any one unit LED-540 can be as the controller of “ MODE ” function. Ensure all the machines in the “non-menu state”[...
- Page 37 Tips： 1、In the shortcut menu, you can switch input port for the bottom layer, but it is not safe behavior, because in the absence of pre-monitoring situation, you can not accurately grasp the switching time. So please determine in advance which of the two inputs would get into the fade switch process.
-
Page 38: Using Mosaic
Using Mosaic Mosaic summarize LED-540 single has two send card slots, two cards can convey the same image for the two LED display at the same time, also can use two cards cascading, and increase the load area for conveying HD image to a high resolution LED display. -
Page 39: Equal Mosaic
“synchronous follow-up”function cannot be successfully launched (namely synchronous follow-up icon are not displayed for a long time), then need to add a LED-540 to do signal shaping, and the above 6 sets LED-540 share the reforming signal by its self DVI loop out port. -
Page 40: Unequal Mosaic
LED-540 LED-540 In the above chart, the input signal of the 6 sets LED-540 from No. 1 and No. 6 are all completely on all fours. To reduce DVI signal loop series, will use the both two LED-540 signal plastic output ports, so can reduce half of the loop series. - Page 41 "synchronous follow-up" function cannot be successfully launched (namely synchronous follow-up icon are not displayed for a long time), then need to add a LED-540 to do signal shaping, and the above four sets LED can share the plastic signal by itself DVI loop out port.
-
Page 42: Multi Machine Connection
Note：The description for the pixel position of LED-540, is starting from 0, namely the top-left corner pixels horizontal and vertical positions are both for 0, increasing from left to right on the horizontal direction, on vertical direction increasing from top to bottom. -
Page 43: Connection Type
Connection type On the left of the rear panel of LED-540, there are two 3.5 mm headset jacks, one marked as “TX” for the communications signals sent port; another is “RX” as a communication signal receiver port. In order to achieve multi machine connection, we need to connect all the machines according to the following picture. - Page 44 Menu state Non-Menu State->FADE function hotkey->Multi Connection Above the diagram, with four LED-540 for example, the arrows represent the flow of DVI signals. Finished the setting of each machine according to above picture, the four machines formed a signal switching station. When need to display the image of the P1 port, just click the“OK”key on no.1 machine,...
- Page 45 figure above. If you need to display image from P4 port, only need to click the “RIGHT”key once on the machine 3. Note that , if the video processor, channel 2 is currently displayed image, through the“input port selection key”can be set to channel 1 input port, if there is no valid signal under the channel 1 port, the left will display a“╳”, if this time on the current video processor, press“OK”or“LEFT”key to perform the fade in and out switch, it will show a black screen.
- Page 46 How to use the hot backup? Enter the“PIP submenu”and select“automatic switching function”, you can set how to use LED-540 hot backup function here. Here are four options, for details please refer to the table below： Item Details Not to use the heat backup function...
- Page 47 LED-540 provides abundant function for the customers, some functions use requires users to have quite a bit of professional knowledge. When you have problems, can try to timing machines, if cannot solve it according the following step, please contact with the local agent, or contact our service department directly.
- Page 48 VGA Image displayed in Press the front panel "AUTO" button until the not full screen image display correct (automatic adjustment, please use the full screen and not take black side signal) PIP display abnormal Check if it is reasonable that the item ...
- Page 49 Model introduction LED-540CX SDI input/loop out Expand external DVI input port Expand external VGA input port Expand external HDMI input port Warranty The whole unit warranty One year (from the buying date); If the invoice is lost, the 60 days after the production date will be the ...
