Altronix ReServ4WP User Manual page 2

To reset the PTC:
1. Temporarily remove wiring from output with tripped PTC (Fig. 2, pg. 3).
2. Eliminate the trouble condition (short circuit or overload).
3. Allow 1 minute for PTC to cool off (reset).
4. Re-attach wiring to the output (Fig. 2, pg. 3).
5. Power LEDs will illuminate indicating power has been restored to outputs (Fig. 2, pg. 3).
WARNING: To reduce the risk of fire or electric shock, do not expose the unit to rain or moisture. This installation
should be made by qualified service personnel and should conform to the National Electrical Code and all local codes.
Power Supply Board
Red (DC) Green (AC1)
ON ON
ON OFF
OFF ON
OFF OFF
ReServ Board
LED LED State
ON
Output LEDs
------
ON
Low Battery
------
ON
Shutdown
------
Power Supply Board
Terminal Legend Function/Description
L, G, N Connect 115VAC 60Hz to these terminals: L to hot, N to neutral.
– DC + 24VDC output.
Form "C" dry contacts used to instantaneously signal the loss AC to local annunciation devices.
AC FAIL
With AC present terminals marked NO and C are open, NC and C are closed.
NO, C, NC
When loss of AC occurs, terminals marked NO and C are closed, NC and C are open.
Form "C" dry contacts used to signal low battery voltage or loss of battery voltage.
BAT FAIL
Under normal conditions terminals marked NO and C are open, NC and C are closed.
NO, C, NC
During a trouble condition terminals marked NO and C are closed, and NC and C are open.
+ BAT – Stand-by battery connections. Maximum charge current 0.7A.
ReServ Board
Terminal Legend Function/Description
Input – 24VDC + 24VDC input from power supply board.
N, P 1-2 12VDC outputs. N = Negative, P = Positive (Fig. 2, pg. 3).
N, P 15-16 24VAC outputs.
The lightning flash with arrow head symbol within an equilateral triangle is intended to alert the user to the presence of an
insulated DANGEROUS VOLTAGE within the product's enclosure that may be of sufficient magnitude to constitute an
electric shock.
The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and
maintenance (servicing) instructions in the literature accompanying the appliance.
ReServ4WP
LED Diagnostics:
Power Supply Status
Normal operating condition.
Loss of AC. Stand-by battery supplying power.
No DC output.
Loss of AC. Discharged or no stand-by battery. No DC output.
Unit Status
------ Normal operating condition.
OFF Loss of 24VAC and/or 12VDC output power.
------ Stand-by batteries are low.
OFF Normal operating condition.
------ Loss of 24VAC and/or 12VDC output power. Discharged stand-by battery.
OFF Normal operating condition.
Terminal Identification:
CAUTION: To reduce the risk of electric shock do not open enclosure.
There are no user serviceable parts inside. Refer servicing to qualified service personnel.
- 2 -
