Running as access point, you can further configure the following settings:
Parameter
Operation type
Radio band
Bandwidth
Channel
Available operation modes are:
Standard
802.11a
802.11b
802.11g
802.11n
802.11ac
Table 5.18.: IEEE 802.11 Network Standards
Note: NetModule Routers with 802.11n and 802.11ac support 2x2 MIMO
Prior to setting up an access point, it is always a good idea to run a network scan for
getting a list of neighboring WLAN networks and then choose the less interfering channel.
Please note that two adequate channels are required for getting good throughputs with
802.11n and a bandwidth of 40 MHz.
Running in managed mode, the access-point can be controlled over CAPWAP (RFC
5415). It establishes a layer-2 tunneling protocol to encrypt transmission of user data
from connected stations. You can configure the following settings:
Parameter
Primary Access Con-
troller
Secondary Access Con-
troller
NB3711 User Manual 4.0
WLAN Management
Specifies the desired IEEE 802.11 operation mode
Selects the radio band to be used for connections, depending
on your module it could be 2.4 or 5 GHz
Specify the channel bandwidth operation mode
Specifies the channel to be used
Frequencies Bandwidth
5 GHz 20 MHz
2.4 GHz 20 MHz
2.4 GHz 20 MHz
2.4/5 GHz 20/40 MHz
5 GHz 20/40/80 MHz
WLAN Management
Specifies the primary access controller
Specifies the secondary access controller
55
Data Rate
54 Mbit/s
11 Mbit/s
54 Mbit/s
300 Mbit/s
866.7 Mbit/s
