Nb3711 Status Indicators - NetModule NB3711 User Manual

Label Color State
Voice
DO1
DO2
DI1
DI2
Ext1
Ext2
[1]
The color of the LED represents the signal quality for wireless links.
red means low
yellow means moderate
green means good or excellent
NB3711 User Manual 4.0
Function
on A voice call is currently active.
off No voice call is active.
on Normally open output port 1 is closed.
off Normally open output port 1 is open.
on Normally closed output port 2 is closed.
off Normally closed output port 2 is open.
on Input port 1 is set.
off Input port 1 is not set.
on Input port 2 is set.
off Input port 2 is not set.
on Extension port 1 is on.
off Extension port 1 is off.
on Extension port 2 is on.
off Extension port 2 is off.
Table 3.1.: NB3711 Status Indicators
