Snmp Agent - NetModule NB3711 User Manual

5.7.10. SNMP Agent

NetModule routers are equipped with an SNMP daemon, supporting basic MIB tables
(such as ifTable), plus additional enterprise MIBs to manage multiple systems.
Parameter
.1.3.6.1.2.1
.1.3.6.1.2.1.2.1
.1.3.6.1.2.1.4
.1.3.6.1.2.1.10.131
.1.3.6.1.2.25
.1.3.6.1.6.3.10
.1.3.6.1.6.3.11
.1.0.8802.1.1.2
.1.0.8802.1.1.2.1.5.4795
.1.3.6.1.4.1.31496
The VENDOR-MIB tables offer some additional information over the system and its
WWAN, GNSS and WLAN interfaces. They can be accessed over the following OIDs:
Parameter
NBAdminTable
NBWwanTable
NBGnssTable
NBDioTable
NBWlanTable
They offer facilities for:
• rebooting the device
• updating to a new system software via FTP/TFTP/HTTP
• updating to a new system configuration via FTP/TFTP/HTTP
• getting WWAN/GNSS/WLAN/DIO information
Our VENDOR-MIB is listed in the appendix or can be downloaded directly from the
router.
NB3711 User Manual 4.0
Supported MIBs
MIB-II (RFC1213), SNMPv2-MIB (RFC3418)
IF-MIB (RFC2863)
IP-MIB (RFC1213)
TUNNEL-MIB (RFC4087)
HOST-RESOURCES-MIB (RFC2790)
SNMP-FRAMEWORK-MIB
SNMPv2-SMI (RFC2578)
LLDP-MIB
LLDP-EXT-MED-MIB
VENDOR-MIB
Vendor MIB OID Assignment
.1.3.6.1.4.1.31496.10.40
.1.3.6.1.4.1.31496.10.50
.1.3.6.1.4.1.31496.10.51
.1.3.6.1.4.1.31496.10.53
.1.3.6.1.4.1.31496.10.60
135
