Microlife WatchBP Office BASIC+ Instruction Manual

Microlife WatchBP Office BASIC+ Instruction Manual

Office blood pressure measurement device with afib detection
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Office blood pressure
measurement device
with Afib detection
Instruction Manual
1
EN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WatchBP Office BASIC+ and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Microlife WatchBP Office BASIC+

Summary of Contents for Microlife WatchBP Office BASIC+

  • Page 1 Office blood pressure measurement device with Afib detection Instruction Manual...

  • Page 3: Table Of Contents

    Table of Contents Product description Special Functions Name of parts ..............3 Mean arterial pressure ..........13 Display ................4 Atrial fibrillation detection ........14-16 Components and accessories ......... 5 Skipping the countdown time ........17 Taking fewer than three measurements ..... 17 Before using WatchBP Office Appendix Selecting and fitting the correct cuff ......

  • Page 4: Product Description

    Product description mmHg Name of parts Display mmHg mmHg /min mmHg Time/Test /min BASIC BASIC USB Port DC 7.5V 2.0A Start/Stop Main Adapter Auscultation button M Button (Memory) Cuff Socket Mode switch Single/Cycling (3, Afib)

  • Page 5: Display

    Display Single Mode Cycling MOde Month/Date Time Auscultation Mode Systolic Value Inflation indicator (for Auscult. Mode) Diastolic Value Memory External Power Number of Stored Data PC Link Indicator Pulse Battery Symbol Mean Arterial Pressure Pulse Rate Interval Time...

  • Page 6: Components And Accessories

    Product and components AC Adaptor X 1 (Input100 - 240V~ 50/60Hz 0.48A; Blood Pressure Device X 1 Output+7.5V 2A) USB Cable mmHg mmHg mmHg /min mmHg Quick start guide /min How to take blood pressure measurement in three different modes mmHg mmHg Plug cuff connector...

  • Page 7: Before Using Watchbp Office Selecting And Fitting The Correct Cuff

    Before using the device Selecting the correct cuff Two different cuff sizes are provided with the device: Medium and Large. Use the cuff marker to select the cuff size that best matches the circumference of the patient’s upper arm. M (Medium size) 22 - 32 cm (8.7 - 12.6 inches) L (Large size) 32-42 cm (12.6 - 16.5 inches)

  • Page 8: Activating The Device

    mmHg mmHg Use the device for the first time mmHg mmHg 2) Set the month – Use the M Button to select the Activating the Device Month. Press the Time/Test Button to confirm. The Day mmHg Open the cover of the battery compartment then plug in mmHg number flashes after.

  • Page 9: Select The Correct Cuff

    Medium and Large. Use the cuff marker to select the cuff mmHg size that best matches the circumference of the patient’s upper arm. please use only Microlife cuffs! /min M (Medium size) BASIC 22 - 32 cm (8.7 - 12.6 inches)

  • Page 10: Connect The Cuff To The Device

    Before using the device (cont.) Connect the cuff to the device Fitting the cuff properly Connect the cuff to the device by inserting the cuff connector 1) Place the cuff over the left (right) upper arm so that the into the cuff connector socket. air tube and artery mark arrow point towards the lower arm.
  • Page 11 5) It may result in incorrect blood pressure readings if the 3) Wrap and tighten the cuff around the arm. cuff does not fit properly. Use a different size cuff if the 4) Leave a little free space between the arm of the patient range index at the end of the cuff does not fall into the and the cuff.

  • Page 12: Three Operation Modes

    Three operation modes: Single, Cycling or Auscultation mode /min mmHg mmHg «Single» Mode Select an operation mode (standard single measurement) There are three measuring modes can be used. Select «Single» Mode then press «Start/Stop» button mmHg BASIC to perform single blood pressure measurement. The Slide the switch to seletct Single mode (standard single mmHg measurement reading is displayed and saved after the...

  • Page 13: Cycling» Mode

    mmHg «Cycling» Mode «AUSCULTATION» Mode (automatic triple measurements) /min Select «Cycling» Mode then press «Start/Stop» button «AUSCULTATION» Mode is used for blood pressure /min to perform automatic triple blood pressure measurement measurement of patients to confirm if a patient is suitable with 60 seconds intervals.

  • Page 14: Viewing The Stored Values

    mmHg mmHg Viewing the stored values Special Functions MAP (Mean Arterial Pressure) Viewing the stored values mmHg The device stores only the blood pressure values of the The device measures the true mean arterial pressured /min last measurement procedure in Single mode and Cycling (MAP) of the patient.
  • Page 15 This device may not detect atrial fibrillation in people with C. Messineo. Detection of Atrial Fibrillation Using a Modified pacemakers or defibrillators. People with pacemakers Microlife Blood Pressure Monitor. or defibrillators should not use this device to detect atrial American Journal of Hypertension 2009; 22, 8, 848–852.

  • Page 16: About Atrial Fibrillation

    Special Function (cont.) About Atrial Fibrillation Atrial fibrillation is a common heart rhythm problem. It The use of blood thinners, such as warfarin, can lower the affects more than 2 million people in North America. It risk of stroke in patients with atrial fibrillation. is more common in older age and it is found in 10% of A doctor can confirm the presence of Afib by using an ECG.

  • Page 17: Atrial Fibrillation Detector

    Atrial Fibrillation Detector Information for the doctor The device can screen for atrial fibrillation during blood This device is designed to detect atrial fibrillation and pressure measurement. false negative readings are very rare. Though it is programmed to specifically detect atrial fibrillation, Some people may have atrial fibrillation occasionally frequent premature beats, marked sinus arrhythmia that lasts longer than a day.

  • Page 18: Skipping The Countdown Time

    mmHg Special Function (cont.) /min Skipping the countdown time Taking fewer than Three measurements mmHg BASIC In «CYCLING» Mode , the measurement sequence can The 15 seconds countdown before measurement in mmHg «CYCLING» Mode can be skipped by pressing the «Start/ be stopped at anytime by pushing the «Start/Stop»...

  • Page 19: Rechargeable Battery And Power Adaptor

    Rechargeable battery and power adaptor Rechargeable Battery Using a power adaptor The device features a built-in, rechargeable Ni-MH battery Please only use the Microlife adaptor supplied with the 400~500 measurement cycles pack that delivers up to device to recharge the device.

  • Page 20: Error Messages

    • tension. Repeat the Please contact your local Microlife service center if the measurement, keeping error persists. your arm still. • If you think the results are unusual, please read through the information in this instruction manual carefully.
  • Page 21 «HI» Pulse or cuff The pressure in the cuff «Err 3» No pressure in An adequate pressure pressure too is too high (over 300 the cuff cannot be generated in high mmHg) OR the pulse is the cuff. A leak may have too high (over 200 beats occurred.

  • Page 22: Safety, Care, Accuracy Test And Disposal

    Safety, care, accuracy test and disposal Safety and protection This device may be used only for the purpose described in Observe the storage and operating conditions described this booklet. The device comprises of sensitive components in the “Technical specifications” section of this manual. and must be treated with caution.

  • Page 23: Accuracy Test

    We recommend the device be tested for accuracy every be disposed of in accordance with the locally 2 years or after mechanical impact (e.g. being dropped). applicable regulations, and not as domestic Please contact Microlife to arrange for an accuracy test. waste.

  • Page 24: Technical Specifications

    Static accuracy: pressure within ± 3 mmHg • Pulse accuracy: ±5 % of the readout value • Voltage source: Rechargeable battery pack; 4.8V, 2400 mAh • Microlife reserves the right to alter technical Mains adapter DC 7.5V, 2 A specfications without prior written notice.

  • Page 25: Guarantee Card

    Guarantee card Name: This device is covered by a two-year guarantee Address: from the date of purchase. This guarantee is valid only on presentation of the guarantee card Date: completed by the owner confirming date of purchase or purchase receipt. Batteries and cuff Telephone: are not covered by this guarantee.
  • Page 26 Europe / Middle-East / Africa Asia North / Central / South America Microlife WatchBP AG Microlife Corporation Microlife U.S.A.,Inc. Espenstrasse 139 9F, 431, RuiGang Road, NeiHu 1617 Gulf To Bay Blvd Floor 2 9443 Widnau, Switzerland Taipei, 114, Taiwan, R.O.C.
