Icom iC-7610 Reference Manual page 8

Remote control
D Command table (Continued)
Cmd. Sub cmd. Data
1A* 05 0137 000001 ~ Network > Serial Port (UDP) (valid after restart)
065535 (000001=1 to 065535=65535)
0138 000001 ~ Network > Audio Port (UDP) (valid after restart)
065535 (000001=1 to 065535=65535)
0139 00 or 01 Network > Internet Access Line (valid after
restart)
( 00=FTTH (Fiber To The Home), 01=ADSL/
0140 see p. 11 Network > Network Radio Name
(Up to 16 characters)
0141 0000 ~ 0255 Display > LCD Backlight
(0000=0% to 0255=100%)
0142 0000 ~ 0255 Display > LED Bright
(0000=0% to 0255=100%)
0143 00 or 01 Display > Display Type
(00=A, 01=B)
0144 00 or 01 Display > Display Font
(00=Basic, 01=Round)
0145 00 ~ 02 Display > Meter Response (Standard,
Edgewise)
(00=Slow, 01=Mid, 02=Fast)
0146 00 ~ 02 Display > Meter Type (Normal Screen)
(00=Standard, 01=Edgewise, 02=Bar)
0147 00 or 01 Display > Meter Type (Expand Screen)
(00=Edgewise, 01=Bar)
0148 00 or 01 Display > Meter Peak Hold (Bar)
(00=OFF, 01=ON)
0149 00 or 01 Display > Memory Name
(00=OFF, 01=ON)
0150 00 or 01 Display > APF-Width Popup (APF OFF→ON)
(00=OFF, 01=ON)
0151 00 ~ 03 Display > Screen Saver
( 00=OFF, 01=15 minutes, 02=30 minutes,
0152 00 or 01 Display > External Display
(00=OFF, 01=ON)
0153 00 or 01 Display > External Display Resolution
(00=800x480, 01=800x600)
0154 00 or 01 Display > Opening Message
(00=OFF, 01=ON)
0155 see p. 11 Display > My Call
(Up to 10 characters)
0156 00 or 01 Display > Power ON Check
(00=OFF, 01=ON)
0157 00 or 01 Display > Display Language
(00=English, 01=Japanese)
0158 20000101 ~ Time Set > Date/Time > Date
20991231 (20000101=2000/01/01 to 20991231=2099/12/31)
0159 0000 ~ 2359 Time Set > Date/Time > Time
(0000=00:00 to 2359=23:59)
0160 00 or 01 Time Set > Date/Time > NTP Function
(00=OFF, 01=ON)
0161 see p. 11 Time Set > Date/Time > NTP Server Address
0162 see p. 13 Time Set > UTC Offset
0163 00 or 01 Time Set > CLOCK2 Function
(00=OFF, 01=ON)
0164 see p. 13 Time Set > CLOCK2 UTC Offset
0165 see p. 11 Time Set > CLOCK2 Name
(Up to 3 characters)
0166 00 or 01 SCOPE > Scope during Tx (CENTER TYPE)
(00=OFF, 01=ON)
0167 00 ~ 02 SCOPE > Max Hold
(00=OFF, 01=10s Hold , 02=ON)
0168 00 ~ 02 SCOPE > CENTER Type Display
( 00=Filter center, 01=Carrier point center,
0169 00 or 01 SCOPE > Marker Position (Fix Type)
(00=Filter center, 01 Carrier point)
0170 00 ~ 03 SCOPE > Averaging
(00=OFF, 01=2, 02=3, 03=4)
0171 00 or 01 SCOPE > Waveform Type
(00=Fill, 01=Fill+Line)
0172 see p. 12 SCOPE > Waveform Color (Current)
0173 see p. 12 SCOPE > Waveform Color (Line)
0174 see p. 12 SCOPE > Waveform Color (Max Hold)
0175 00 or 01 SCOPE > Waterfall Display
(00=OFF, 01=ON)
Description
CATV)
03=60 minutes)
02=Carrier point center (Abs. Freq.))
Cmd. Sub cmd. Data
1A* 05 0176 00 ~ 02
0177 00 ~ 02
0178 00 ~ 09
0179 00 or 01
0180 00 or 01
0181 00 or 01
0182 see p. 12
0183 see p. 12
0184 see p. 12
0185 see p. 12
0186 see p. 12
0187 see p. 12
0188 see p. 12
0189 see p. 12
0190 see p. 12
0191 see p. 12
0192 see p. 12
0193 see p. 12
0194 see p. 12
0195 see p. 12
0196 see p. 12
0197 see p. 12
0198 see p. 12
0199 see p. 12
0200 see p. 12
0201 see p. 12
0202 see p. 12
0203 see p. 12
0204 see p. 12
0205 see p. 12
0206 see p. 12
0207 see p. 12
0208 see p. 12
0209 see p. 12
0210 see p. 12
0211 see p. 12
0212 see p. 12
0213 see p. 12
0214 see p. 12
0215 see p. 12
0216 see p. 12
0217 see p. 12
0218 00 or 01
0219 see p. 12
0220 00 or 01
0221 see p. 12
0222 00 ~ 04
0223 01 ~ 08
0224 0001 ~ 9999 KEYER 001 > Present Number
0225 0000 ~ 0255 CW-KEY SET > Side Tone Level
0226 00 or 01
0227 01 ~ 60
0228 28 ~ 45
7
Description
SCOPE > Waterfall Speed
(00=Slow, 01=Mid, 02=Fast)
SCOPE > Waterfall Size (Expand Screen)
(00=Small, 01=Mid, 02=Large)
SCOPE > Waterfall Peak Color Level
(00=Grid 1 to 09=Grid 10)
SCOPE > Waterfall Marker Auto-hide
(00=OFF, 01=ON)
SCOPE > Dual Scope Type
(00=Over/Under, 01=Side by Side)
SCOPE > Dual Scope Auto Select
(00=OFF, 01=ON)
SCOPE > Fixed Edges > 0.03 – 1.60 No.1
SCOPE > Fixed Edges > 0.03 – 1.60 No.2
SCOPE > Fixed Edges > 0.03 – 1.60 No.3
SCOPE > Fixed Edges > 1.60 – 2.00 No.1
SCOPE > Fixed Edges > 1.60 – 2.00 No.2
SCOPE > Fixed Edges > 1.60 – 2.00 No.3
SCOPE > Fixed Edges > 2.00 – 6.00 No.1
SCOPE > Fixed Edges > 2.00 – 6.00 No.2
SCOPE > Fixed Edges > 2.00 – 6.00 No.3
SCOPE > Fixed Edges > 6.00 – 8.00 No.1
SCOPE > Fixed Edges > 6.00 – 8.00 No.2
SCOPE > Fixed Edges > 6.00 – 8.00 No.3
SCOPE > Fixed Edges > 8.00 – 11.00 No.1
SCOPE > Fixed Edges > 8.00 – 11.00 No.2
SCOPE > Fixed Edges > 8.00 – 11.00 No.3
SCOPE > Fixed Edges > 11.00 – 15.00 No.1
SCOPE > Fixed Edges > 11.00 – 15.00 No.2
SCOPE > Fixed Edges > 11.00 – 15.00 No.3
SCOPE > Fixed Edges > 15.00 – 20.00 No.1
SCOPE > Fixed Edges > 15.00 – 20.00 No.2
SCOPE > Fixed Edges > 15.00 – 20.00 No.3
SCOPE > Fixed Edges > 20.00 – 22.00 No.1
SCOPE > Fixed Edges > 20.00 – 22.00 No.2
SCOPE > Fixed Edges > 20.00 – 22.00 No.3
SCOPE > Fixed Edges > 22.00 – 26.00 No.1
SCOPE > Fixed Edges > 22.00 – 26.00 No.2
SCOPE > Fixed Edges > 22.00 – 26.00 No.3
SCOPE > Fixed Edges > 26.00 – 30.00 No.1
SCOPE > Fixed Edges > 26.00 – 30.00 No.2
SCOPE > Fixed Edges > 26.00 – 30.00 No.3
SCOPE > Fixed Edges > 30.00 – 45.00 No.1
SCOPE > Fixed Edges > 30.00 – 45.00 No.2
SCOPE > Fixed Edges > 30.00 – 45.00 No.3
SCOPE > Fixed Edges > 45.00 – 60.00 No.1
SCOPE > Fixed Edges > 45.00 – 60.00 No.2
SCOPE > Fixed Edges > 45.00 – 60.00 No.3
AUDIO SCOPE SET > FFT Scope Waveform Type
(00=Line, 01=Fill)
AUDIO SCOPE SET >
FFT Scope Waveform Color
AUDIO SCOPE SET >
FFT Scope Waterfall Display
(00=OFF, 01=ON)
AUDIO SCOPE SET >
Oscilloscope Waveform Color
KEYER 001 > Number Style
( 00=Normal, 01=190→ANO, 02=190→ANT,
03=90→NO, 04=90→NT)
KEYER 001 > Count Up Trigger
(01=M1 to 08=M8)
(0001=1 to 9999=9999)
(0000=0% to 0255=100%)
CW-KEY SET > Side Tone Level Limit
(00=OFF, 01=ON)
CW-KEY SET > Keyer Repeat time
(01=1 sec. to 60=60 sec.)
CW-KEY SET > Dot/Dash Ratio
(28=1:1:2.8 to 45=1:1:4.5; 0.1 steps)
