Icom iC-7610 Reference Manual page 5

Remote control
D Command table (Continued)
Cmd. Sub cmd. Data
15 07 00 or 01 Read the Overflow status
( 00=OVF indicator is OFF, 01=OVF indicator is ON)
11 0000 ~ 0255 Read the PO meter level
(0000=0% to 0143=50% to 212=100%)
12 0000 ~ 0255 Read SWR meter level
( 0000=SWR1.0, 0048=SWR1.5,
13 0000 ~ 0255 Read ALC meter level
(0000=Min. to 0120=Max.)
14 0000 ~ 0255 Read COMP meter level
(0000=0 dB, 0130=15 dB, 0241=30 dB)
15 0000 ~ 0255 Read Vd meter level
(0000=0 V, 0151=10 V, 0211=16 V)
16 0000 ~ 0255 Read Id meter level
( 0000=0A, 0077=10A, 0165=20A, 0241=30A)
16* 02 00 Preamp OFF
01 Preamp 1 ON
02 Preamp 2 ON
12 01 ~ 03 Set the AGC time constant
(01=FAST, 02=MID, 03=SLOW)
22 00 or 01 Set the Noise blanker
(00=OFF, 01=ON)
32 00 Audio peak filter OFF
01 Audio peak filter WIDE ON
(320 Hz is selected when SHARP APF is set)
02 Audio peak filter MID ON
(160 Hz is selected when SHARP APF is set)
03 Audio peak filter NAR ON
(80 Hz is selected when SHARP APF is set)
40 00 or 01 Set the Noise reduction
(00=OFF, 01=ON)
41 00 or 01 Set the Auto Notch function
(00=OFF, 01=ON)
42 00 or 01 Set the Repeater tone
(00=OFF, 01=ON)
43 00 or 01 Set the Tone squelch
(00=OFF, 01=ON)
44 00 or 01 Set the Speech compressor
(00=OFF, 01=ON)
45 00 or 01 Set the Monitor [MONI] function
(00=OFF, 01=ON)
46 00 or 01 Set the VOX function
(00=OFF, 01=ON)
47 00 BK-IN function OFF
01 Semi BK-IN function ON
02 Full BK-IN function ON
48 00 or 01 Set the Manual Notch function
(00=OFF, 01=ON)
4E 00 or 01 Set the DIGI-SEL function
(00=OFF, 01=ON)
4F 00 or 01 Set the Twin peak filter
(00=OFF, 01=ON)
( Can be turned ON only when Mark and Shift
50 00 or 01 Set the Dial lock function
(00=OFF, 01=ON)
53* 00 or 01 Set the ANT-RX I/O
2
(00=OFF, 01=ON)
56 00 or 01 Set the DSP IF filter type
(00=SHARP, 01=SOFT)
57 00 ~ 02 Set the Manual Notch width
(00=WIDE, 01=MID, 02=NAR)
58 00 ~ 02 Set the SSB transmit bandwidth
(00=WIDE, 01=MID, 02=NAR)
( One of following values is applied, depending
5E 00 or 01 MAIN/SUB Tracking function
(00=OFF, 01=ON)
65 00 or 01 Set the IP Plus function
(00=OFF, 01=ON)
Description
0080=SWR2.0, 0120=SWR3.0)
are set to 2125 Hz and 170 Hz, respectively)
on the "COMP" status (ON or OFF):
WIDE (Command: 1A 05 0015),
MID (Command: 1A 05 0016) or
NAR (Command: 1A 05 0017))
Cmd. Sub cmd. Data
17* see p. 10
3
18 00
01*
4
19 00
1A* 00 see p. 11
01 see p. 10
02* see p. 13
6
03 see p. 12
04 see p. 12
05 0001 see p. 12
0002 00 ~ 10
0003 00 ~ 10
0004 see p. 12
0005 00 ~ 10
0006 00 ~ 10
0007 see p. 12
0008 00 ~ 10
0009 00 ~ 10
0010 see p. 12
0011 see p. 12
0012 see p. 12
0013 00 ~ 10
0014 00 ~ 10
0015 see p. 12
0016 see p. 12
0017 see p. 12
0018 00 ~ 10
0019 00 ~ 10
0020 00 ~ 10
0021 00 ~ 10
0022 0000 ~ 0255 Function > Beep Level
0023 00 or 01
0024 00 or 01
0025 00 or 01
02
03
4
Description
Send CW messages
Turn OFF the transceiver
Turn ON the transceiver
Read the transceiver ID
Send/read memory contents
Send/read band stacking register contents
Send/read memory keyer contents
Send/read the selected IF filter width
Send/read the selected AGC time constant
Tone Control > RX >
Send/read SSB RX HPF/LPF settings
Tone Control > RX >
Send/read SSB RX Tone (Bass) level
(00=–5 to 10=+5)
Tone Control > RX >
Send/read SSB RX Tone (Treble) level
(00=–5 to 10=+5)
Tone Control > RX >
Send/read AM RX HPF/LPF settings
Tone Control > RX >
Send/read AM RX Tone (Bass) level
(00=–5 to 10=+5)
Tone Control > RX >
Send/read AM RX Tone (Treble) level
(00=–5 to 10=+5)
Tone Control > RX >
Send/read FM RX HPF/LPF settings
Tone Control > RX >
Send/read FM RX Tone (Bass) level
(00=–5 to 10=+5)
Tone Control > RX >
Send/read FM RX Tone (Treble) level
(00=–5 to 10=+5)
Tone Control > RX >
Send/read CW RX HPF/LPF settings
Tone Control > RX >
Send/read RTTY RX HPF/LPF settings
Tone Control > RX >
Send/read PSK RX HPF/LPF settings
Tone Control > TX >
Send/read SSB TX Tone (Bass) level
(00=–5 to 10=+5)
Tone Control > TX >
Send/read SSB TX Tone (Treble) level
(00=–5 to 10=+5)
Tone Control > TX >
Send/read SSB TX bandwidth for wide
Tone Control > TX >
Send/read SSB TX bandwidth for mid
Tone Control > TX >
Send/read SSB TX bandwidth for narrow
Tone Control > TX >
Send/read AM TX Tone (Bass) level
(00=–5 to 10=+5)
Tone Control > TX >
Send/read AM TX Tone (Treble) level
(00=–5 to 10=+5)
Tone Control > TX >
Send/read FM TX Tone (Bass) level
(00=–5 to 10=+5)
Tone Control > TX >
Send/read FM TX Tone (Treble) level
(00=–5 to 10=+5)
(0000=min. to 0255=max.)
Function > Beep Level Limit
(00=OFF, 01=ON)
Function > Beep (Confirmation)
(00=OFF, 01=ON)
Function > Band Edge Beep
(00=OFF, 01=ON)
( ON = Beep sounds with a default amateur
band)
Function > Band Edge Beep
(02=ON (User))
Function > Band Edge Beep
(03=ON (User) & TX Limit)
