Remote control
D Command formats (Continued)
• Scope waveform data
Command: 27 00
Outputs the waveform data to the controller
q w e r
X X X X X X X X
q Main or Sub scope data
• 00=Main scope, 01=Sub scope
w Order of division data (Current)
e Division number (01 or 15)
When data is sent to the controller through the
LAN port, all data is sent together. However,
when the data is sent through the USB port, the
data is divided by 15 and sent in sequential order.
Division number
LAN 01
USB 15
The 1st data sends only the wave information (q
~ y) without the waveform data (u).
The 2nd or later data sends the minimum wave
information (q ~ e) with waveform data (u).
r Center or Fixed mode data
• 00 = Center mode scope,
01 = Fixed mode scope
t Waveform information
The waveform information is different between
Center mode and fixed mode.
• In the Center mode: Center frequency and span are
sent
See page 10 for Frequency data, and the Scope span
settings to the right.
• In the Fixed mode: Lower edge and higher edge
frequencies are sent
See page 15 for Scope Fixed edge frequency settings
e ~ !2 .
y Out of range information
• 00 = In range, 01 = Out of range
If the scope data is out of range, the waveform data
(u) is omitted.
u Waveform data
The transceiver outputs the drawn waveform data.
The data range or data length of the waveform data is
judged by the controller. (The data range is basically
the same as the display size of the scope on the
controller.)
Data range
Data length
t y u
X X X X X X ...... X X
Data length
704
1st data 15
2nd or
53
later data
15th data 42
0 ~ 200
689
• Center/Fixed mode settings
Command: 27 14
X X X X
00=MAIN
01=SUB
• Scope span settings
Command: 27 15
q w e
X X 0 0 X X X X 0 0 0 0
00=MAIN
01=SUB
• Scope Edge number settings
Command: 27 16
X X X X
00=MAIN
01=SUB
• Scope Hold settings
Command: 27 17
X X X X
00=MAIN
01=SUB
14
00=Center mode
01=Fixed mode
r t y
Span (kHz)
2500
5000
10000
25000
50000
100000
250000
500000
01=Edge 1
02=Edge 2
03=Edge 3
00=Hold OFF
01=Hold ON
2.5
5
10
25
50
100
250
500
