Icom iC-7610 Reference Manual page 16

Remote control
D Command formats (Continued)
• Scope Reference level settings
Command: 27 19
X X X X X 0 X X
00= MAIN
01= SUB
L Adjustable range: –30.0 dB ~ +10.0 dB in 0.5 dB steps
• Scope Sweep speed settings
Command: 27 1A
X X X X
00=MAIN
01=SUB
• Scope VBW (Video Band Width) settings
Command: 27 1D
X X X X
00=MAIN
01=SUB
• Scope RBW (Resolution Band Width) settings
Command: 27 1F
X X X X
00=MAIN
01=SUB
00= + (plus)
01= – (minus)
00=FAST
01=MID
02=SLOW
00=Narrow
01=Wide
00=WIDE
01=MID
01=NAR
• Scope Fixed edge frequency settings
Command: 27 1E
q w e r t
X X 0 X X X X X X X X X 0 0 X X X X X X X X 0 0
Lower edge
L Entry of 100 Hz or smaller digits are ignored.
q Selectable Frequency ranges
Data Frequency range (Hz)
01 0.03 ~ 1.60
02 1.60 ~ 2.00
03 2.00 ~ 6.00
04 6.00 ~ 8.00
05 8.00 ~ 11.00
06 11.00 ~ 15.00
07 15.00 ~ 20.00
08 20.00 ~ 22.00
09 22.00 ~ 26.00
10 26.00 ~ 30.00
11 30.00 ~ 45.00
12 45.00 ~ 60.00
w Selectable Edge number: 01=1, 02=2, 03=3
15
y u i o !0 !1
Higher edge
!2
