Nomenclature - GRAPHTEC GL2000 Quick Start Manual

Top Panel Top Panel Top Panel
USB memory terminal
Front Panel Front Panel Front Panel
FAN air exit
SD card slot
External input/output terminals
Bottom Panel Rear Panel
Bottom Panel Bottom Panel
The illustration without cover is used for explanation purpose.

Nomenclature

Power jack for humidity sensor
Analog signal input terminals
USB interface terminal
LAN interface terminal
Operation status LED
Monitor Control panel keys
Label
Battery cover
Input terminals
AC adapter jack
GND terminal
Power switch
Tilt stand fixing screw
Tilt foot
FAN air exit
