5. Device access display (SD card)
: SD card is not attached.
: SD card is attached but not being accessed.
: SD card is accessed. Do not remove SD card. The POWER LED light also flashes while the SD card is
being accessed.
Please do not remove the SD card and do not turn Off this device's power when accessing the SD card.
The data is damaged, and it will not be accessable.
6. Device access display (USB memory)
: USB memory is not attached.
: USB memory is attached but not being accessed.
: USB memory is accessed. Do not remove USB memory. The POWER LED light also flashes while the
USB memory is being accessed.
Please do not remove the USB memory and do not turn Off the power when accessing the USB memory.
The data is damaged, and it will not be accessable.
7. Remote lamp
: Indicates local mode. Operations can be conducted on this device.
: Indicates remote mode. With some exceptions, operations must be conducted on a PC.
When you cancel the connection on the application (GL980_2000-APS), this device automatically rerturns to local
mode. If local mode is not entered, press the [QUIT] key.
8. Key lock display
: Not in key lock status. Normal operations are permitted
: Key lock status. All the keys are locked.
For details of the key lock, refer to "3.4 Setting Menus" - "(14)Key lock release with password".
