Table Of Contents - GRAPHTEC GL2000 Quick Start Manual

Thank you for choose the midi LOGGER HV GL2000.
This Quick Start Guide describes the basic operations.
Please refer to the manual (PDF) in the CD-ROM for more information.
The explanation on how to use the ferrite core, tilt stand, and M3.5 screw
can be found in the manual above. Please refer to them.
Checking the Outer Casing
After unpacking, check the GL2000's Exterior to make sure that
there are crack or other damage before use.
Checking the Accessories
• Quick Start Guide : 1
• AC cable/AC adapter : 1
• M3.5 screws: 1 set • Notes for Safe Operation: 1
Nomenclature ............................................................... 2
Connection Procedures ...................................................3
Precautions to Observe When Taking Measurementt ............ 5
Descriptions of the Control Panel Keys .............................. 6
Descriptions of the Menu Screens ................................. 10
Measurement Procedure ................................................ 14
1. Preparation for measurement .........................................................14
2. AMP setting .............................................................................. 15
3. DATA setting ..............................................................................17
4. Recording and stopping ............................................................... 18
5. Playback method ........................................................................ 19
Specifications ...............................................................20
Standard Specifications ..................................................................20
Specification of input section ............................................................ 21
Specification of Input/Output section ................................................... 22
Installation Guide .........................................................
1
• Ferrite core: 3 • CD-ROM : 1
• Tilt stand: 1 set
Contents
22
