L e v e l ™ T L M & T L L e v e r E x p l o d e d V i e w
Hose
Hose boot
Compression nut
Bleed port
screws (2)
Pivot pin
Reservoir bolts (2)
Reservoir cap
Bladder
Lever body
Lever blade bushings (2)
Piston assembly
Washer
Snap ring
Inboard spring
Lever blade
Level™ TLM & TL Lever Exploded View
SwingLink™
push rod
Spring
bushing
