Using Navios Software
Analysis Menu
See also:

Setting a New Dual Prism Divider

Editing a Dual Prism Divider

Setting a New Dual Prism Divider
1
Highlight the chosen dual parameter plot (current window).
2
Analysis > Create Prism Divider > Dual Prism Divider
3
A Dual Prism cursor
4
Position the cursor anywhere on the window, click to show the prism divider lines. If
pressed at this point the operation is abandoned.
5
Move cursor to position crosshair then click to set position.
Editing a Dual Prism Divider
Editing an existing Dual Parameter plot with a set of dual Prism dividers displayed essentially
consists of creating a new set of dual Prism dividers. When the second set of dual Prism dividers is
defined the first set is deleted.
1
Highlight the required dual parameter plot.
2
Mouse over the Prism divider to get the
3
+ hold to set the new Dual Prism crosshair. When the new dividers are set they replace the
previously set dividers. Any associated Prism plot is updated with the new Prism statistics.
Any associated Prism plot changes its format and has its statistics updated to reflect a smaller
number of Prism dividers and a smaller number of displayed phenotypes.
10-136
is displayed in the current window.
, or
.
cursor.
( )
is
Esc
773232AH
