Putting A Bar-Code Label On A Sample Tube - Beckman Coulter Navios Instructions For Use Manual

System Overview
Learning The Basic Operating Techniques
CAUTION
Sample misidentification can occur from the use of incorrect, poor quality,
damaged, dirty or improperly placed bar-code labels. Follow the
Specifications
identification. Bar-code label incorrectly placed on sample tubes could cause
misidentified tubes. To prevent misidentified samples, affix the bar-code label as
shown below so the MCL can read the label.

Putting a Bar-Code Label on a Sample Tube

1
Carefully align the label with the tube.
2
Press the label down securely, including edges and corners, without wrinkles or folds.
1. 25.4 mm (1.0 in.) minimum
2. 7.5 degrees.
5-8
to create your bar-code labels to prevent incorrect sample
Bar-code
c
b
c
773232AH
