MVP™ Driver QRG
Using Both
For a resolution of 2048 x 640 max. (doubling the 1024 and
increasing the 512 to 640), using the pixel ratio of the panel,
Signal Outputs
calculate the number of panels as follows.
to Increase
Screen
MPV™ 18 (32 x 32): 2048 / 32 = 64
Resolution
640 / 32 = 20
Because you are using both outputs, one output will connect to
one half of your video wall and the other will connect to the other
half. The result is two sections that are 32 panels x 10 panels
each, or 320 panels in total in each section. Refer to the
following example.
32 (1/2) + 32 (1/2) = 64
1024 = 32 panels
U (MAIN)
320 = 10 panels
D
320 = 10 panels
10 (1/2) + 10 (1/2) = 20
1024 = 32 panels
Page 10 of 12
