A100K10333 v.5.5

3.2 IP Configuration

In the 'IP Settings' page (Configuration tab > Network Settings
menu > IP Settings page item) enter the IP Address, Subnet Mask
and optionally the Default Gateway Address of the AudioCodes
Gateway.
This IP address must be identical to the IP address of the SIP Trunk
Node created in AlphaPro.
Click Submit to apply the changes.
Note: The IP address is immediately changed when pressing Submit, but it is
not permanently stored. Without resetting or powering off the device,
you need to log on to the Gateway using its new IP address in order to
Burn the new IP address to flash:
Disconnect the PC from the Gateway.
Reconnect the Gateway and PC to the LAN.
The PC and Gateway must be on the same sub-net.
Restore the PC's IP address and subnet mask to what they originally
were, and re-access the Gateway using the new assigned IP
address.
Click Burn to permanently apply the changes.

3.3 SIP Parameters

In the 'Proxy & Registration' page (Configuration tab > Protocol
Configuration menu > Protocol Definition submenu > Proxy &
Registration page item) set the 'Use Default Proxy' field to 'Yes'.
Click the Proxy Set Table button. In the 'Proxy Address' field enter
the IP address of the AlphaCom.
Set 'Transport Type' to 'UDP'.
Press Submit to save changes

3.4 Audio Codec

Select the voice coder in 'Coders Table' page (Configuration tab >
Protocol Configuration menu > Protocol Definition submenu >
Coders page item). Choose G.711U-law Coder Name, 20 ms
Packetization Time and Silence Suppression Disabled.
