3.8 Telephone Network to AlphaCom

You can choose between three different ways of handling an incoming
call from the telephone line:

Selective Dialing

Automatic Dialing
Delayed Automatic Dialing
3.8.1 Selective Dialing
A second dial tone will be presented when calling in, and the user can
dial the desired intercom number. The fields in the 'Automatic Dialing'
page item must be left blank (Default setting).
(Configuration tab > Protocol Configuration menu > Endpoint
Settings submenu > Automatic Dialing page item).
In this mode the gateway collects digits from the line, and sets up the
call towards the AlphaCom when a predefined number of digits are
collected and no more digits are received within a preset time (default 4
seconds), or when the '#' key is dialed.
In the 'DTMF & Dialing' page (Configuration tab > Protocol
Configuration menu > Protocol Definition submenu > DTMF &
Dialing page item) select 'Advanced Parameter List' in order to view all
parameters, and set 'Max Digits In Phone Num' equal to the number of
digits used on the AlphaCom stations, normally 3 or 4.
The parameter 'Inter Digit Timeout for Overlap Dialing' specifies the
waiting time for more digits before setting up the call.

3.8.2 Automatic Dialing (Call to Switchboard)

When calling in, the call will automatically be connected to a predefined
intercom number.
Enter the intercom number in the 'Destination Phone Number' field in
the 'Automatic Dialing' page item. Set 'Auto Dial Status' to 'Enable'.
(Configuration tab > Protocol Configuration menu > Endpoint
Settings submenu > Automatic Dialing page item).
