Press Submit to save changes

3.5 About Saving Changes

The Submit button will save the data to the running volatile memory.
The changes take effect on-the-fly. The changes will not survive
hardware reset or power off.
To permanently save the configuration data, store the data to flash
memory by selecting Burn from the Tool Bar.
Note: Parameters proceeded by a yellow lightning symbol is not changeable
on-the-fly and require that the device is reset.

3.6 Backup and Restore

The configuration of the AudioCodes Gateway can be stored to a file on
your PC.
From the Tool Bar select Device Actions -> Save Configuration File.
Select Save INI File to save the configuration to the PC, and select
Load INI File to upload a configuration file to the SIP Gateway.

3.7 AlphaCom to Telephone Network

There are two ways of selecting a FXO line from the AlphaCom.
Group Hunt, where a prefix is dialed and you are connected to one
out of several lines
Direct FXO line selection, where there is one prefix assigned for
each of the FXO lines.
The two methods can be combined.

3.7.1 Group Hunt

Dial a prefix and get connected to a free FXO line.
Hunt Group Settings
In the 'Hunt Group Settings' page (Configuration tab > Protocol
Configuration menu > Hunt/IP Group submenu > Hunt Group
Settings page item) set the 'Hunt Group ID' field to '1' and 'Channel
Select Mode' to 'Cyclic Ascending'.
IP to Hunt Group Routing
When dialing the prefix from AlphaCom, the call needs to be routed to
the appropriate Hunt Group ID associated with the FXO ports.
