Users can either use one of the supplied configuration (dat) files found
on the CD provided with the gateway, or construct their own file.
A file with the most common tone patterns can also be downloaded from
www.zenitel.com/stentofon/support
To construct your own file, either:
Modify the supplied usa_tone.ini file (in any standard text editor) to
suit the specific requirements, and convert the modified ini file into
binary format using the TrunkPack Downloadable Conversion
Utility.
Or:
Use the Call Progress Tones Wizard.
The Call Progress Tones Wizard (CPTWizard) is an application
designed to detect the Call Progress Tones generated by your PBX
(or telephone exchange) to create a basic Call Progress Tones ini
file containing definitions for all relevant Call Progress Tones. This
provides a good starting point when configuring the SIP gateway.
This ini file can then be converted to a dat file using the TrunkPack
Downloadable Conversion utility.
Both the TrunkPack Downloadable Conversion Utility
(DConvert.exe) and the Call Progress Tones Wizard (CPTWizard.exe)
can be found on the AudioCodes CD.
Load a Call Progress Tones (dat) file to the SIP gateway:
Select Management tab > Software Update menu > Load Auxiliary
Files page item.
Click the Browse button and navigate to the folder that contains the
file you want to load
Click the file and click the Open button; the name and path of the file
appear in the field beside the Browse button
Click the Load File button
Burn the configuration so the file can be available after a power
failure
Reset the SIP Gateway for the changes to take effect
For more detailed information regarding Call Progress Tones please
refer to the AudioCodes User's Manual found on the CD supplied with
the unit.
