ALPHACOM CONFIGURATION

Configuration example
A100K10333 v.5.5
10.5.101.42
255.255.255.0
The configuration of AlphaCom E with SIP gateway includes the
following steps:
Using AlphaWeb
Assign IP address to the AlphaCom Ethernet port
Insert SIP Trunk licenses
Firewall (filter) settings
Using AlphaPro
Create a SIP Trunk Node
Define the AlphaCom / SIP routing
Create prefix numbers
Update the exchange

2.1 AlphaWeb Configuration

2.1.1 Assign IP address to the AlphaCom E Ethernet
port(s)
Log on to AlphaWeb and enter a valid IP address on the Ethernet
port. In the example below, Ethernet port 1 is used.
Consult your network administrator to obtain the IP address.
Configuration Guide
AudioCodes MP-114/118
10.5.101.44
255.255.255.0
SIP trunk
PSTN / PABX
GSM
Analogue
FXO ports
DECT
ISDN
