6

MISCELLANEOUS FEATURES

Page 18

6.1 Incoming Calls in Private

Incoming calls from the telephone line can be forced to be in private
ringing mode, independent of the private/open switch of the intercom
station.
Check the flag Incoming calls from SIP in private ringing mode in
AlphaPro, (Exchange & System > System > VoIP).

6.2 Door Opening Feature

During a conversation between a door station and a telephone, the
telephone operator can activate the Door Opening feature in the
AlphaCom by pressing digit 6.

6.2.1 SIP Gateway configuration

To enable digit actions from the telephone line during conversation, set
st
'1 Tx DTMF Option' to 'INFO(Cisco)' in the 'DTMF & Dialing' page.
(Configuration tab > Protocol Configuration menu > Protocol
Definition submenu > DTMF & Dialing page item).

6.2.2 AlphaCom configuration

The Door Opening feature is programmed in the Event Handler. There
are two separate events for the door opening feature, depending on who
is the calling side:
calling from the telephone to the door
calling from the door to the telephone
Calling from the telephone to the door:
The Standard door opening event is used.
Calling from the door to the telephone:
When the phone presses digit 6, the event type Event Trigger Feature
(15) is reported, with the digit 6 as sub event. The calling AlphaCom
station is Event Owner, and called SIP phone number and node number
is Related To. The RCO pulse time is specified as an additional
parameter in the RCO action string, i.e. RCO 3 ON 20 means pulse
RCO 3 for 2 seconds.
Configuration Guide
AudioCodes-114/118
A100K10333 v.5.5
