Cygnus MR400 Taximeter User Guide

2 The MR400 Taximeter

"Rate
Window"
Used to show
the rate being
charged. Also
used for other
purposes.
Tariff Programming
Connector (Covered
by Seal Retainer)
Figure 1: Front Panel Features
2
Mode
Indicator.
Here Showing
that the meter
is in "Hired"
mode.
Operating Buttons:
SELECT
REVERT
MODE
TOTAL
EXTRAS
"Fare Window".
Shows the Fare
being charged.
Also used for
other purposes.
Seal to prevent
unauthorised
tampering with the
Taximeter
"Extras Window"
Shows the Extras
being charged. Also
used for other
purposes.
Seal to prevent
unauthorised
removal and
replacement of
the taximeter in
the vehicle.
