CASTING REMOVAL & SERVICE
Remove rebound knob using a
1
2mm hex wrench.
Insert an 8mm hex wrench into the
2
end of the rebound damper rod and
turn the rod clockwise until it is
disengaged from the casting and
can be pushed into the casting.
Use a 12mm wrench to remove the
3
compression rod bolt.
