Manitou Circus Expert Service Manual page 21

CASTING INSTALL
Slide casting onto the stanchion
4
assembly. Only slide the casting down
about halfway at this point. Take care
that the seals do not get folded over on
installation.
Insert 15cc's (15ml) of semi-bath into
5
each casting leg. Once the semi-bath is
in the legs slide the casting the rest of
the way onto the stanchion assembly.
Using an 8mm hex wrench tighten the
6
rebound damper rod and air spring
assembly to 35–40in lbs [3.95–4.5 Nm]
by turning them counter-clockwise. Do
not overtighten, doing so can damage
the end of the rods.
