  • Page 1 Automatic Identification System Model JHS-180 Operation Manual (Field Maintenance)

  • Page 2: Table Of Contents

    CONTENTS 1.Field Maintenance mode 1.1 Turning On the power for Field Maintenance mode 1.2 Menu Tree of Field Maintenance mode 2. FIELD MAINTENANCE 2.1 SELF TEST 2.2 COMM STATUS 2.3 REPORTING RATE 2.4 SELF TEST LOG 2.5 RANGE ALARM LOG 2.6 PORT LOG 2.7 PORT OPTION 2.8 TRX CHECK...

  • Page 3: Field Maintenance Mode

    1.1 Turning On the power for Field Maintenance mode JHS-180 can operate “Field Maintenance Mode” for installation and maintenance. To operate “Field Maintenance Mode”, JHS-180 needs special operation in turning the power on. The special operation is; When turn the power on, pressing and holding [PWR] and [MENU] until starting display “AIS CONTROLLER NOW LOADING ---”...

  • Page 4: Menu Tree Of Field Maintenance Mode

    1.2 Menu Tree of Field Maintenance mode (Power On:[MENU]+[PWR]) Select(1) key (Power On) [▲]/[▼],[ENT] Other Ship's detail Information Other Ships List [0]-[9] or [▲]/[▼],[ENT] [0]-[9] or [▲]/[▼],[ENT] [0]-[9] or [▲]/[▼],[ENT] [MENU] [MENU]key 3.MAIN MENU 1.MESSAGE 1.EDIT AND TX Destination address Message type Message editing Transmission...

  • Page 5: Field Maintenance

    2. FIELD MAINTENANCE “FIELD MAINTENANCE” menu is displayed by pressing 8 key in the “Main Menu”. Display of “FIELD MAINTENACE”...

  • Page 6: Self Test

    2.1 SELF TEST “SELF TEST” menu is displayed by pressing 1 key in the “FIELD MAINTENANCE” menu. Display of “SELF TEST” (All result is OK) Display of “SELF TEST” (All result is fault) Display of “SELF TEST” (Time out)
  • Page 7 Indication of failures in NTE-180 AIS Transponder Control unit Indication TRX unit Indication CPU(FLASH ROM) FROM CPU(SRAM) SRAM Temperature TEMP Ext. FLASH ROM EFROM Forward power Serial Reverse power Communication Access Serial I/O Digital Up Converter GPS receiver GPS Information GPS-INFO...

  • Page 8: Comm Status

    2.2 COMM STATUS “COMM STATUS” menu is displayed by pressing 2 key in the “FIELD MAINTENANCE” menu. Display of “COMM STAUS”...

  • Page 9: Reporting Rate

    2.3 REPORTING RATE “REPORTING RATE” menu is displayed by pressing 3 key in the “FIELD MAINTENANCE” menu. Display of “REPORTING RATE”...

  • Page 10: Self Test Log

    2.4 SELF TEST LOG “SELF TEST LOG” menu is displayed by pressing 4 key in the “FIELD MAINTENANCE” menu. Display of “SELF TEST LOG”...

  • Page 11: Range Alarm Log

    2.5 RANGE ALARM LOG “RANGE ALARM LOG” menu is displayed by pressing 5 key in the “FIELD MAINTENANCE” menu. Display of “RANGE ALARM LOG”...

  • Page 12: Port Log

    2.6 PORT LOG “PORT LOG” menu is displayed by pressing 6 key in the “FIELD MAINTENANCE” menu. Display of “PORT LOG” Details of each port is displayed by pressing from 1 to 1 key in the “PORT LOG” menu. Display of “SENSOR1 LOG”...

  • Page 13: Port Option

    2.7 PORT OPTION “PORT OPTION” menu is displayed by pressing 7 key in the “FIELD MAINTENANCE” menu. Display of “PORT OPTION”...

  • Page 14: Trx Check

    2.8 TRX CHECK “TRX CHECK” menu is displayed by pressing 8 key in the “FIELD MAINTENANCE” menu. Display of “TRX CHECK” “RX CHANNEL CHECK” menu is displayed by pressing 1 key in the “TRX CHECK” menu. Display of “RX CHANNEL CHECK”...
  • Page 15 “TX POWER CHECK” menu is displayed by pressing 2 key in the “TRX CHECK” menu. Display of “TX POWER CHECK” “TX POWER ADJUS” menu is displayed by pressing 3 key in the “TRX CHECK” menu. Display of “TX POWER ADJUST”...

  • Page 16: Software Ver Up

    2.9 SOFTWARE VER UP “SOFWARE VER UP” menu is displayed by pressing 9 key in the “FIELD MAINTENANCE” menu. Display of “SOFTWARE VER UP” Display of transponder version up in “SOFTWARE VERSION UP”...
  • Page 17 Display of controller version up in “SOFTWARE VERSION UP”...
  • Page 18 2.10 STATE INITIALIZE “STATE INITIALIZE” is displayed by pressing 0 key in the “FIELD MAINTENANCE” menu. Display of “STATE INITIALIZE”(OFF) Display of “STATE INITIALIZE”(ON)

  • Page 19: Initialize

    3. INITIALIZE “INITIALIZE” menu is displayed by pressing 9 key in the “Main Menu”. Display of “INITIALIZE”...

  • Page 20: Sensor Setting

    3.1 SENSOR SETTING “SENSOR SETTING” menu is displayed by pressing 1 key in the “INITIALIZE” menu. Display of “SENSOR SETTING” Each sensor filter menu is displayed by pressing from 1 to 5 key in the “SENSOR SETTING” menu. Display of each sensor filter setting in “SENSOR SETTING”...

  • Page 21: Int. Gps Setting

    3.2 INT. GPS SETTING “INT. GPS SETTING” menu is displayed by pressing 2 key in the “INITIALIZE” menu. Display of “INT. GPS SETTING”...

  • Page 22: Ship Static Data

    3.3 SHIP STATIC DATA “SHIP STATIC DATA” menu is displayed by pressing 3 key in the “INITIALIZE” menu. Display of “SHIP STATIC DATA”...

  • Page 23: Transponder Init

    3.4 TRANSPONDER INIT “TRANSPONDER INIT” menu is displayed by pressing 4 key in the “INITIALIZE” menu. Display of “TRANSPONDER INIT”...

  • Page 24: Antenna Selection

    3.5 ANTENNA SELECTION “ANTENNA SELECTION” menu is displayed by pressing 5 key in the “INITIALIZE” menu. Dispaly of “ANTENNA SELECTION”...
