Cobalt Digital Inc 9083 Product Manual

Hd/sd frame sync with audio embedding/de-embedding and dolby encoder with dolby encoder option +encd or +ence
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
HD/SD Frame Sync
with Audio Embedding/De-Embedding and Dolby
9083+ENCD – with Dolby
9083+ENCE – with Dolby
Product Manual
9083
With Dolby
+ENCD or +ENCE
®
Digital™Encoder Option
®
E™Encoder Option
Cobalt Digital Inc.
2406 E. University Ave.
Urbana, IL 61802
Voice 217.344.1243 • Fax 217.344.1245
www.cobaltdigital.com
®
Encoder Option
®
Encoder
9083-ENC-OM (V4.4)

Advertisement

Table of Contents
loading

Related Manuals for Cobalt Digital Inc 9083

Summary of Contents for Cobalt Digital Inc 9083

  • Page 1 With Dolby Encoder Option +ENCD or +ENCE HD/SD Frame Sync ® with Audio Embedding/De-Embedding and Dolby Encoder ® 9083+ENCD – with Dolby Digital™Encoder Option ® 9083+ENCE – with Dolby E™Encoder Option Product Manual Cobalt Digital Inc. 2406 E. University Ave.

  • Page 2: Trademark Information

    Furthermore, Cobalt Digital Inc. reserves the right to make changes to any products herein to improve readability, function, or design. Cobalt Digital Inc. does not assume any liability arising out of the application or use of any product or circuit described herein.

  • Page 3: Table Of Contents

    E Encoder Description (+ENCE only) ........1-17 User Control Interface ................1-19 9083 Rear I/O Modules ................1-21 Audio and Video Formats Supported by the 9083 ........1-23 Technical Specifications..................1-24 Warranty and Service Information ............... 1-28 Cobalt Digital Inc. Limited Warranty............1-28 Contact Cobalt Digital Inc..................
  • Page 4 DashBoard™ User Interface ............... 3-3 ® Cobalt Remote Control Panel User Interfaces .......... 3-4 Accessing the 9083 Card via Remote Control ............3-5 Accessing the 9083 Card Using DashBoard™ ........... 3-5 Accessing the 9083 Card Using a Cobalt ® Remote Control Panel ..... 3-6 Checking 9083 Card Information................
  • Page 5 Measurement Techniques For Various Program Material Forms........A-3 Importance of an Anchor Element ................ A-4 Assumptions and Conditions For Meaningful LKFS Measurements ....Specific Measurement Techniques for Various Material Forms ......Modifying LKFS Assessments Using Parametric Settings ......... 9083-ENC-OM (V4.4) 9083 (WITH DOLBY ENCODING OPTION) PRODUCT MANUAL...
  • Page 6 This page intentionally blank 9083 (WITH DOLBY ENCODING OPTION) PRODUCT MANUAL 9083-ENC-OM (V4.4)

  • Page 7: Chapter 1 Introduction

    Also provides general information regarding the 9083. • Chapter 2, “Installation and Setup” – Provides instructions for installing the 9083 in a frame, and optionally installing 9083 Rear I/O Modules. • Chapter 3, “Operating Instructions” – Provides overviews of operating controls and instructions for using the 9083.

  • Page 8: 9083 Card Software Versions And This Manual

    The Software Version of your card can be checked by viewing the Card Info menu in DashBoard™. See Checking 9083 Card Information (p. 3-7) in Chapter 3, “Operating Instructions” for more information. You can then check our website for the latest software version currently released for the card as described below.

  • Page 9: Manual Conventions

    Introduction Manual Conventions Manual Conventions In this manual, display messages and connectors are shown using the exact name shown on the 9083 itself. Examples are provided below. • Card-edge display messages are shown like this: Ch01 • Connector names are shown like this:...

  • Page 10: Labeling Symbol Definitions

    Cards with many heat-producing components should be arranged to avoid areas of excess heat build-up, particularly in frames using only convection cooling. The 9083 has a moderate power dissipation (15 W max.). As such, avoiding placing the card adjacent to other cards with similar dissipation values if possible.

  • Page 11: 9083 Functional Description

    The input/output complement listed above represents the maximum capability of the 9083. The practical input/output complement is determined by the par- ticular Rear I/O Module used with the 9083. Refer to 9083 Rear I/O Modules (p. 1-21) for more information.
  • Page 12 9083 Functional Description Figure 1-1 9083 Functional Block Diagram 9083 (WITH DOLBY ENCODING OPTION) PRODUCT MANUAL 9083-ENC-OM (V4.4)

  • Page 13: Video Functions Description

    A Reset Framesync function resets the frame sync following any horizontal or vertical offset changes, clearing any buffered audio and video and re-establishing the frame sync. The 9083 re-establishes video/audio sync following framesync changes by applying an offset in small, progressive amounts to provide a seamless, glitch-free retiming.
  • Page 14 SDI ATC_LTC Proc/Embed Detect/Extract HD/SD–SDI Video Output Insert Control Line Number Control Audio/ Audio LTC Audio LTC Out Audio/RS-485 RS-485 LTC Select/Extract LTC Generate RS-485 LTC Out Figure 1-2 Timecode Processor 9083 (WITH DOLBY ENCODING OPTION) PRODUCT MANUAL 9083-ENC-OM (V4.4)

  • Page 15: Audio Processor Description

    AES inputs can be set to use sample rate converters to align these inputs with the output timing. (AES must be nominally 48 kHz input; 32, 44.1, 96, and 192 kHz inputs are not compatible with the 9083.) The sample rate converters are disabled by default. Output AES is always precisely synchronized with the output video.
  • Page 16 • AES Ch 8 • Embed Ch 8 AES Ch 8 Embedded Audio Note: The 9083 with +ENCD or +ENCE Group 3/4 option receives up to 16 channels of AES Ch 9 Embed Ch 9 • discrete AES audio, but is not equipped •...
  • Page 17 , and , this indicates to the upmixer that the channel(s) are already carrying viable 5.1 content. In this case, the upmixer is bypassed, allowing the original channels to pass unaffected. 1-11 9083-ENC-OM (V4.4) 9083 (WITH DOLBY ENCODING OPTION) PRODUCT MANUAL...
  • Page 18 Note: In either case shown here, the unselected channels (in this example, Emb Ch 7 thru Ch 16) are not involved in this process and always pass unaffected. Figure 1-6 Up Mix Auto Enable/Bypass with Example Sources 1-12 9083 (WITH DOLBY ENCODING OPTION) PRODUCT MANUAL 9083-ENC-OM (V4.4)

  • Page 19: Aes Audio Input Advanced Features

    9083 Functional Description Tone Generator Function The 9083 contains four built-in tone generators (Tone Generator 1 thru Tone Generator 4). Each of the four tone generators can be set to a different frequency, and are available as audio sources for the embedded or AES audio outputs.

  • Page 20: Audio Lkfs Monitor Description

    Digital (AC-3) Encoder. The six user-selected audio sources are ® mapped to thru , which are then fed to the Dolby Audio Encr Ch 1 Encr Ch 6 Encode function. 1-14 9083 (WITH DOLBY ENCODING OPTION) PRODUCT MANUAL 9083-ENC-OM (V4.4)
  • Page 21 To AES (AES 1- 16) Status OUT 5-8 (AN-AUD 1- 8) Display (4X Copies) (DM-L,R) (MONO) (Tone 1- 4) (Silence) ® Figure 1-7 Dolby Digital (AC-3) Encoder Functional Block Diagram 1-15 9083-ENC-OM (V4.4) 9083 (WITH DOLBY ENCODING OPTION) PRODUCT MANUAL...
  • Page 22 AES-3id port). Note: On the encoder-equipped 9083, AES Audio Out pairs 5-8 serve as four dedi- cated copies of the encoded pair in addition to any other encoded pair routing. The encoded AC-3 data rate can be selected from multiple choices with associated audio quality trade-offs.

  • Page 23: Dolby ® E Encoder Description (+Ence Only)

    Dolby E Encoder. The eight user-selected audio sources are mapped to ® thru , which are then fed to the Dolby Audio Encode Encr Ch 1 Encr Ch 8 function. 1-17 9083-ENC-OM (V4.4) 9083 (WITH DOLBY ENCODING OPTION) PRODUCT MANUAL...
  • Page 24 (allowing the encoded pair to be available over a discrete AES-3id port). Note: On the encoder-equipped 9083, AES Audio Out pairs 5-8 serve as four dedi- cated copies of the encoded pair in addition to any other encoded pair routing. 1-18 9083 (WITH DOLBY ENCODING OPTION) PRODUCT MANUAL 9083-ENC-OM (V4.4)

  • Page 25: User Control Interface

    Introduction 9083 Functional Description User Control Interface Figure 1-9 shows the user control interface options for the 9083. These options are individually described below. Note: All user control interfaces described here are cross-compatible and can oper- ate together as desired. Where applicable, any control setting change made using a particular user interface is reflected on any other connected interface.
  • Page 26 Built-in Card Edge User Interface – Using the built-in card edge controls and display, card control settings can be set using a front panel menu. Note: Some of the 9083 functions described in this manual are available only when ® using the DashBoard™, or Cobalt OGCP-9000 or OGCP-9000/CC Remote Control Panels user interfaces.

  • Page 27: 9083 Rear I/O Modules

    Rear I/O Module; the unused inputs and outputs remain unterminated and not available for use. The full assortment of 9083 Rear I/O Modules is shown and described in 9083 Rear I/O Modules (p. 2-6) in Chapter 2, “Installation and Setup”.
  • Page 28 9083 Functional Description Figure 1-11 shows a 9083 card using an RM20-9083-B Rear I/O Module. Using this Rear I/O Module, this module provides industry standard break-out connections for the following inputs and outputs required by this application: • Inputs: • HD/SD SDI IN –...

  • Page 29: Audio And Video Formats Supported By The 9083

    44.1 kHz, 96 kHz or 192 kHz rates. Discrete AES Audio Output The 9083 can provide 8 channels (AES pairs 1 thru 4) of discrete AES audio on 75Ω BNC connections. (1) All rates displayed as frame rates; interlaced (“i”) field rates are two times the rate value shown.

  • Page 30: Technical Specifications

    Technical Specifications Technical Specifications Table 1-2 lists the technical specifications for the 9083 HD/SD Frame Sync ® with Audio Embedding/De-Embedding and Dolby Encoder Option card. Table 1-2 Technical Specifications Item Characteristic Part number, nomenclature • 9083+ENCD – HD/SD Frame Sync with Audio Embedding/ ®...
  • Page 31 < 0.10 UI (all outputs) Overshoot: < 0.2% of amplitude Pre-Processor (Reclocked) Serial Digital Number of Outputs: Video Outputs Two HD/SD-SDI BNC per IEC 60169-8 Amendment 2 Impedance: 75 Ω 1-25 9083-ENC-OM (V4.4) 9083 (WITH DOLBY ENCODING OPTION) PRODUCT MANUAL...
  • Page 32 RS-485 Metadata / LTC I/O Metadata extracted from input video (per SMPTE 2020-1-2008) or ® input to Dolby encoder, or LTC I/O on RS-485 interface; 3-wire balanced via Phoenix terminal block connector. 1-26 9083 (WITH DOLBY ENCODING OPTION) PRODUCT MANUAL 9083-ENC-OM (V4.4)
  • Page 33 1 Vp-p nominal Signal Type: Analog video sync (black burst or tri-level) Impedance: 75 Ω Return Loss: > 30 dB to 30 MHz Allowable Maximum DC on Ref Input: ±1.0 V 1-27 9083-ENC-OM (V4.4) 9083 (WITH DOLBY ENCODING OPTION) PRODUCT MANUAL...

  • Page 34: Warranty And Service Information

    (1) year. Cobalt Digital Inc.'s (“Cobalt”) sole obligation under this warranty shall be limited to, at its option, (i) the repair or (ii) replacement of the product, and the determination of whether a defect is covered under this limited warranty shall be made at the sole discretion of Cobalt.

  • Page 35: Contact Cobalt Digital Inc

    Name and address of your local dealer • Product information and pricing • Technical support • Upcoming trade show information Phone: (217) 344-1243 Fax: (217) 344-1245 Web: www.cobaltdigital.com General Information: info@cobaltdigital.com Technical Support: support@cobaltdigital.com 1-29 9083-ENC-OM (V4.4) 9083 (WITH DOLBY ENCODING OPTION) PRODUCT MANUAL...
  • Page 36 This page intentionally blank 1-30 9083 (WITH DOLBY ENCODING OPTION) PRODUCT MANUAL 9083-ENC-OM (V4.4)

  • Page 37: Chapter 2 Installation And Setup

    This procedure is applicable only if any of the four AES I/O (1-4) ports on the 9083 are to be used as outputs (the switches are set to input mode by factory default). The 9083 is equipped with a four-section red DIP switch that sets AES pairs 1 thru 4 as either inputs or outputs.

  • Page 38: Installing The 9083 Into A Frame Slot

    Cards with many heat-producing components should be arranged to avoid areas of excess heat build-up, particularly in frames using only convection cooling. The 9083 has a moderate power dissipation (15 W max.). As such, avoiding placing the card adjacent to other cards with similar dissipation values if possible.
  • Page 39 I/O module, proceed to card installation steps below. • If installing the 9083 in a slot with no rear I/O module, a Rear I/O Module is required before cabling can be connected. Refer to Installing a Rear I/O Module (p.
  • Page 40 Installing the 9083 Into a Frame Slot Repeat steps 1 through 8 for other 9083 cards. Note: The 9083 BNC inputs are internally 75-ohm terminated. It is not necessary to terminate unused BNC inputs or outputs. Note: External frame sync reference signals are received by the card over a refer- ence bus on the card frame, and not on any card rear I/O module connectors.

  • Page 41: Installing A Rear I/O Module

    The full assortment of 9083 Rear I/O Modules is shown and described in 9083 Rear I/O Modules (p. 2-6). Install a Rear I/O Module as follows: On the frame, determine the slot in which the 9083 is to be installed. In the mounting area corresponding to the slot location, install Rear I/O Module as shown in Figure 2-2.

  • Page 42: 9083 Rear I/O Modules

    RM20-9083-A/S Rear I/O Module to function as inputs, AES I/O switches S11 – S12 must be set to Input (factory default). See Setting I/O Switches for AES I/O (1-4) Ports (p. 2-1) for more information. 9083 (WITH DOLBY ENCODING OPTION) PRODUCT MANUAL 9083-ENC-OM (V4.4)
  • Page 43 Input (factory default). See Setting I/O Switches for AES I/O (1-4) Ports (p. 2-1) for more information. Note: AES OUT 1 and AES OUT 2 on RM-9083-C Rear I/O Module always function as outputs regardless of whether AES I/O 1 or AES I/O 2 are used as inputs or outputs.
  • Page 44 • Two buffered SDI coaxial outputs (SDI OUT 1 and SDI OUT 2) Note: For AES I/O 1 thru AES I/O 4 on RM20-9083-D Rear I/O Module to function as inputs, AES I/O switches S11 – S14 must be set to Input (factory default).
  • Page 45 • Two buffered SDI coaxial outputs (SDI OUT 1 and SDI OUT 2) Note: For AES IN 1 thru AES IN 4 on RM20-9083-F Rear I/O Module to function as inputs, AES I/O switches S11 – S14 must be set to Input (factory default).
  • Page 46 • Two buffered SDI coaxial outputs (SDI OUT 1 and SDI OUT 2) Note: For AES I/O 1 thru AES I/O 4 on RM-9083-J Rear I/O Module to function as inputs, AES I/O switches S11 – S14 must be set to Input (factory default).
  • Page 47 • One HD/SD-SDI reclocked input copy (RCK OUT 1) • Two buffered SDI coaxial outputs (SDI OUT) Note: Available equipped with High-Density BNC (HDBNC) or DIN1.0/2.3 connectors as: RM20-9083-E-HDBNC or RM20-9083-E-DIN, respectively. 2-11 9083-ENC-OM (V4.4) 9083 (WITH DOLBY ENCODING OPTION) PRODUCT MANUAL...

  • Page 48: Setting Up 9083 Network Remote Control

    ® Board Remote Control Setup Guide as a download, or contact Cobalt listed in Contact Cobalt Digital Inc. (p. 1-29). • If installing a card in a frame already equipped for, and connected to DashBoard™, no network setup is required for the card. The card will be dis- covered by DashBoard™...

  • Page 49: Chapter 3 Operating Instructions

    Control and Display Descriptions This section describes the user interface controls, indicators, and displays for using the 9083 card. The 9083 functions can be accessed and controlled using any of the user interfaces described here. The format in which the 9083 functional controls, indicators, and displays appear and are used varies depending on the user interface being used.

  • Page 50: Function Submenu/Parameter Submenu Overview

    The functions and related parameters available on the 9083 card are organized into function submenus, which consist of parameter groups as shown below. Figure 3-1 shows how the 9083 card and its submenus are organized, and also provides an overview of how navigation is performed between cards, function submenus, and parameters.

  • Page 51: Dashboard™ User Interface

    GUI drop-down lists. (In this manner, the setting effected using controls and selection lists displayed in DashBoard™ are comparable to the submenu items accessed and committed using the 9083 card edge controls.) Typical Selection...

  • Page 52: Cobalt ® Remote Control Panel User Interfaces

    0.0 dB 0.0 dB In this example, Gain for Embedded Channel 1 is adjusted using the corresponding Gain control OGCP_GEN.JPG knob. Figure 3-3 Control Panel Setup of Example Audio Control Function 9083 (WITH DOLBY ENCODING OPTION) PRODUCT MANUAL 9083-ENC-OM (V4.4)

  • Page 53: Accessing The 9083 Card Via Remote Control

    On the computer connected to the frame LAN, open DashBoard™. As shown below, in the left side Basic View Tree locate the Network Controller Card associated with the frame containing the 9083 card to be accessed (in this example, “MFC-8320-N SN: 00108053”).

  • Page 54: Accessing The 9083 Card Using A Cobalt

    • Rotate any knob to select from the list of devices. The device selected using a knob order number of the device that is displayed with a reversed background (in this example, “1 9083 - Receiver 21 is ready for selection Input Processing”).

  • Page 55: Checking 9083 Card Information

    The Tree View shows the cards seen by DashBoard™. In this example, Network Controller Card MFC-8320-N (serial number ...8053) is hosting a 9083 card in slot 7. Software Version Number Refer to this number to check that documentation (such as this manual) matches the card’s Software Version Number.

  • Page 56: Ancillary Data Line Number Locations And Ranges

    Dolby Metadata = 13 CC = 10 AFD (now on line 18) AFD = 18 Dolby Metadata = 13 resolved Card n Card 1 Figure 3-5 Example VANC Line Number Allocation Example 9083 (WITH DOLBY ENCODING OPTION) PRODUCT MANUAL 9083-ENC-OM (V4.4)

  • Page 57: 9083 Function Submenu List And Descriptions

    9083 Function Submenu List and Descriptions 9083 Function Submenu List and Descriptions Table 3-2 individually lists and describes each 9083 function submenu (“tab”) and its related list selections, controls, and parameters. Where helpful, examples showing usage of a function are also provided. Table 3-2 is primarily based upon using DashBoard™...

  • Page 58: Audio Input Controls

    Note: AES audio must be nominally 48 kHz. • Enabled: In this mode, AES SRC for the corresponding AES input pair is enabled. SRC enabled allows the 9083 to interface with asynchronous AES sources (sources in which the AES timing does not match the video reference timing).
  • Page 59 The 9083 card does not perform Dolby decoding on the • signal. Although the 9083 controls will appear to be usable for this signal tag, the signal is passed with 1-to-1 routing and all related gain and polarity controls set to unity.
  • Page 60 When set to Enabled, gangs Gain, Phase, and Mute controls for same-numbered Embedded and AES channels 1 thru 8. Ganging is bilateral, with Embedded channel control settings affecting corresponding AES channel controls, and vice-versa. 3-12 9083 (WITH DOLBY ENCODING OPTION) PRODUCT MANUAL 9083-ENC-OM (V4.4)

  • Page 61: Afd

    Locations and Ranges (p. 3-8) for more information. • The card does not check for conflicts on a given line number. Make certain the selected line is available and carrying no other data. 3-13 9083-ENC-OM (V4.4) 9083 (WITH DOLBY ENCODING OPTION) PRODUCT MANUAL...
  • Page 62 When Framesync is enabled and set to Input Video, allows disabling audio SRC. This is required if the card is to pass non-PCM audio such as Dolby® audio to downstream devices. 3-14 9083 (WITH DOLBY ENCODING OPTION) PRODUCT MANUAL 9083-ENC-OM (V4.4)
  • Page 63 Video: Audio: 40 msec 440 msec In this example, initial offset of 400 msec (appr. 12 frames) is above 9 frame threshold and results in immediate hard resync. 3-15 9083-ENC-OM (V4.4) 9083 (WITH DOLBY ENCODING OPTION) PRODUCT MANUAL...
  • Page 64 • Freeze Last Frame: Freeze image to last good frame (last frame having valid SAV and EAV codes). • Freeze to Color: Freeze image to a color raster (as selected using Framesync LOS Freeze Color control). 3-16 9083 (WITH DOLBY ENCODING OPTION) PRODUCT MANUAL 9083-ENC-OM (V4.4)

  • Page 65: Framesync

    • Click Yes to reset the frame sync. Reset Framesync • Click No to reject reset. Note: These controls are not normally used or required when the card is receiving a stable, continuous frame sync reference. 3-17 9083-ENC-OM (V4.4) 9083 (WITH DOLBY ENCODING OPTION) PRODUCT MANUAL...

  • Page 66: Embedded Audio Group 1/2

    Note: After familiarizing yourself with the controls described in the audio routing/control sections that follow, see “Audio Routing Example Using DashBoard™” (p. 3-58) in “Example Setups Using The 9083 and DashBoard™” for a full example using these controls.

  • Page 67: Embedded Audio Group 1/2

    AES channel (Ch 1 thru Ch 16) to be the source for the selected destination Embedded Audio Group channel. (In this example, AES Ch 1 is the source for destination Embedded Ch 1) • • • 3-19 9083-ENC-OM (V4.4) 9083 (WITH DOLBY ENCODING OPTION) PRODUCT MANUAL...
  • Page 68 (In this example, Tone 1 (tone generator 1) is the source for destination Embedded Ch 1) Note: Tone generator frequencies can be independently set for the four tone generator sources. Refer to Tone Generator function description on page 3-40 for more information. 3-20 9083 (WITH DOLBY ENCODING OPTION) PRODUCT MANUAL 9083-ENC-OM (V4.4)
  • Page 69 Allows pushbutton On/Off channel muting while saving all other settings. • Phase Control Selects between Normal and Invert phase (relative to source original phase) for the destination Embedded Audio Group channel. 3-21 9083-ENC-OM (V4.4) 9083 (WITH DOLBY ENCODING OPTION) PRODUCT MANUAL...
  • Page 70 DM–(L, R, Mono) CH15 and 2 (not shown here). 0 dB Additional sources not shown DM-L CH16 here are also available. DM-R Encoded Pair 0 dB Embedded D 1/2 Audio Group 4 3-22 9083 (WITH DOLBY ENCODING OPTION) PRODUCT MANUAL 9083-ENC-OM (V4.4)

  • Page 71: Embedded Audio Group 3/4

    Embedded Ch 1. Refer to Embedded Audio Group 1/2 on page 3-18 for descriptions of these controls. • For each channel, its source and destination should be considered and appropriately set. Unused destination channels should be set to the Silence selection. 3-23 9083-ENC-OM (V4.4) 9083 (WITH DOLBY ENCODING OPTION) PRODUCT MANUAL...

  • Page 72: Audio Lkfs Monitor

    (for example, as in the case of intended channels not being “seen” by the LKFS monitor due to desired embedded channels being directed to AES output and not embedded output channels). 3-24 9083 (WITH DOLBY ENCODING OPTION) PRODUCT MANUAL 9083-ENC-OM (V4.4)
  • Page 73 AC-3 program coding serves as Dashboard-configurable internal metadata setting) target LKFS value (in this example, -27 LKFS) serves as target LKFS value (in this example, -24 LKFS) 3-25 9083-ENC-OM (V4.4) 9083 (WITH DOLBY ENCODING OPTION) PRODUCT MANUAL...
  • Page 74 Sets the allowable time an out of range measured LKFS (as set above) can loiter, after which results in an LKFS out of range alarm display. (0 to 30 sec range in 1-second steps; default = 1.0 sec) 3-26 9083 (WITH DOLBY ENCODING OPTION) PRODUCT MANUAL 9083-ENC-OM (V4.4)

  • Page 75: Aes Audio Out Pairs 1-4

    Routing Example Using DashBoard™ (p. 3-58) for more AES Ch 7 ® examples of using these Dolby 0 dB controls. Encoded Pair Encd Pair 1/2 –6 dB AES Ch 8 3-27 9083-ENC-OM (V4.4) 9083 (WITH DOLBY ENCODING OPTION) PRODUCT MANUAL...
  • Page 76 (Ch 1 thru Ch 8) to be the source for the selected destination AES channel. (In this example, Analog Ch1 is the source for destination AES Ch 1) • • • 3-28 9083 (WITH DOLBY ENCODING OPTION) PRODUCT MANUAL 9083-ENC-OM (V4.4)

  • Page 77: Audio Mixing

    (In this example, audio LTC is the source for destination AES Ch 1) Note: • When LTC is selected as source, Gain and Mute controls are disabled. • Refer to Timecode function description on page 3-36 for more information. 3-29 9083-ENC-OM (V4.4) 9083 (WITH DOLBY ENCODING OPTION) PRODUCT MANUAL...
  • Page 78 • Mute Control Allows pushbutton On/Off channel muting while saving all other settings. • Phase Control Selects between Normal and Invert phase (relative to source original phase) for the destination AES channel. 3-30 9083 (WITH DOLBY ENCODING OPTION) PRODUCT MANUAL 9083-ENC-OM (V4.4)
  • Page 79 (0.0 dB to -10.0 dB range in 0.1 dB steps; default = -3 dB) Note: Default setting of -3.0 dB is recommended to maintain center-channel predominance in downmix representative to that of the original source 5-channel mix. 3-31 9083-ENC-OM (V4.4) 9083 (WITH DOLBY ENCODING OPTION) PRODUCT MANUAL...
  • Page 80 AN-AUD Ch 1- Ch 8 MONO Emb Ch 12 Σ Emb Ch 16 Note: Selection of any two channels for mono mixing in no way affects the source channels themselves. 3-32 9083 (WITH DOLBY ENCODING OPTION) PRODUCT MANUAL 9083-ENC-OM (V4.4)
  • Page 81 LFE – Emb Ch 4 Emb Ch 3 Ls – Emb Ch 5 Emb Ch 4 (LFE) Rs – Emb Ch 6 Emb Ch 5 (Ls) Emb Ch 6 (Rs) 3-33 9083-ENC-OM (V4.4) 9083 (WITH DOLBY ENCODING OPTION) PRODUCT MANUAL...
  • Page 82 Slower settings allow for a more gradual transition between modes, however with a longer interval before levels stabilize. Faster settings conversely allow for a smaller interval before levels stabilize, however with greater perceived abruptness. 3-34 9083 (WITH DOLBY ENCODING OPTION) PRODUCT MANUAL 9083-ENC-OM (V4.4)
  • Page 83 Ls or Rs level, with Ls and Rs content progressively folded back into L and R, respectively. (0% to 100% range in 0.1% steps; default = 100%) 3-35 9083-ENC-OM (V4.4) 9083 (WITH DOLBY ENCODING OPTION) PRODUCT MANUAL...

  • Page 84: Timecode

    ATC_LTC Insertion = Enabled Extract Line Number ATC_VITC1 = Line 9 (default SMPTE 12M-2) Control ATC_VITC2 = Line 8 (571) (default SMPTE 12M-2) ATC_LTC = Line 10 (default SMPTE 12M-2) 3-36 9083 (WITH DOLBY ENCODING OPTION) PRODUCT MANUAL 9083-ENC-OM (V4.4)
  • Page 85 Note: When the Scaler is enabled, ATC packets are automatically removed. The Timecode function must be used to re-insert the timecode data into the output video. 3-37 9083-ENC-OM (V4.4) 9083 (WITH DOLBY ENCODING OPTION) PRODUCT MANUAL...
  • Page 86 • Offset Field delays or advances or delays timecode by one field. • Offset Frame delays or advances or delays timecode by up to 5 frames. Note: Default settings are null, with both controls set at zero as shown. 3-38 9083 (WITH DOLBY ENCODING OPTION) PRODUCT MANUAL 9083-ENC-OM (V4.4)
  • Page 87 “field 1” packet (non-toggling). Note: Non-toggling VITC1 and VITC2 packets do not conform to SMPTE 12M-2-2008 preferences. As such, ATC_VITC Legacy Support should be enabled only if required by downstream equipment. 3-39 9083-ENC-OM (V4.4) 9083 (WITH DOLBY ENCODING OPTION) PRODUCT MANUAL...

  • Page 88: Tone Generator

    To order features and obtain a license key, contact Cobalt sales at sales@cobaltdigital.com or at the contact information in Contact Cobalt Digital Inc. in Chapter 1, “Introduction”. Please provide the “SSN” number of your card (displayed in the Card Info pane) when contacting us for your key.
  • Page 89 • Text entry field provides for optional entry of card name, function, etc. (as shown in this example). • Card Name Note: Card name can be 31 ASCII characters maximum. 3-41 9083-ENC-OM (V4.4) 9083 (WITH DOLBY ENCODING OPTION) PRODUCT MANUAL...

  • Page 90: Presets

    • After uploading a presets file, engagement of a desired preset is only assured by pressing the Preset Load button for a desired preset. 3-42 9083 (WITH DOLBY ENCODING OPTION) PRODUCT MANUAL 9083-ENC-OM (V4.4)

  • Page 91: Dolby ® Digital (Option +Encd Only) Functions Submenu List

    Note: After familiarizing yourself with the controls described in the Dolby functions sections that follow, see “Dolby Digital™ (AC-3) Setup and Routing Example” (p. 3-61) in “Example Setups Using The 9083 and DashBoard™” (p. 3-58) for a full example using these controls. • Encoding Mode Selects audio input fed to the encoder as shown to the left.
  • Page 92 After observing the program status/description, the desired external source can be selected using the AC-3 Metadata Source drop-down list described above (Program 1 as shown here and selected in the example above). 3-44 9083 (WITH DOLBY ENCODING OPTION) PRODUCT MANUAL 9083-ENC-OM (V4.4)
  • Page 93 • Last Received External Metadata is being used: When enabled (as described above), indicates last received external metadata is being used as a failover in lieu of valid current external metadata. 3-45 9083-ENC-OM (V4.4) 9083 (WITH DOLBY ENCODING OPTION) PRODUCT MANUAL...

  • Page 94: Dolby Digital External Metadata

    Note: Metadata does not continuously report. Use this button to report new metadata. When clicked, the button stays in the “depressed” position while updating. When the button displays the “out” position, update is complete and all displays are current. 3-46 9083 (WITH DOLBY ENCODING OPTION) PRODUCT MANUAL 9083-ENC-OM (V4.4)
  • Page 95 AC-3 programs • • • For each AC-3 program as applicable, individual audio production parametric settings and bitstream information is displayed in accordance with the programming inherent in the received metadata. 3-47 9083-ENC-OM (V4.4) 9083 (WITH DOLBY ENCODING OPTION) PRODUCT MANUAL...

  • Page 96: Dolby Digital Internal Metadata

    For an internally generated metadata, individual audio production parametric settings and bitstream information controls allow setup. Drop-down lists provide on/off settings or selection from a range of appropriate choices in ® general conformance with Dolby Digital (AC-3) encoding and ATSC A/52B practices. 3-48 9083 (WITH DOLBY ENCODING OPTION) PRODUCT MANUAL 9083-ENC-OM (V4.4)

  • Page 97: Dolby Digital Channel Mapping

    AES, analog, downmix, mono, or tone generator audio source as shown to the left. • • • • • • • • • • • • 3-49 9083-ENC-OM (V4.4) 9083 (WITH DOLBY ENCODING OPTION) PRODUCT MANUAL...

  • Page 98: Dolby ® E (Option +Ence Only) Functions Submenu List

    Note: The AES Audio Out Pairs 5-8 tab is not available or displayed in DashBoard™for the 9083. Instead, the encoded pair (when active) is available as copies on AES Out pairs 5 thru 8 regardless of other output routing selections.

  • Page 99: Dolby E Encoder

    Note: After familiarizing yourself with the controls described in the Dolby functions sections that follow, see “Dolby E Setup and Routing Example” (p. 3-63) in “Example Setups Using The 9083 and DashBoard™” (p. 3-58) for a full example using these controls. • Encoding Mode Selects audio input fed to the encoder as shown to the left.

  • Page 100: Dolby E External Metadata

    Note: When encoding is active, it is recommended to set Metadata Removal to On. Because the valid metadata for the newly encoded audio is now carried in the encoded audio stream, removal of previous SMPTE 2020 VBI metadata is recommended. 3-52 9083 (WITH DOLBY ENCODING OPTION) PRODUCT MANUAL 9083-ENC-OM (V4.4)
  • Page 101 Note: Metadata does not continuously report. Use this button to report new metadata. When clicked, the button stays in the “depressed” position while updating. When the button displays the “out” position, update is complete and all displays are current. 3-53 9083-ENC-OM (V4.4) 9083 (WITH DOLBY ENCODING OPTION) PRODUCT MANUAL...
  • Page 102 AC-3 programs • • • For each AC-3 program as applicable, individual audio production parametric settings and bitstream information is displayed in accordance with the programming inherent in the received metadata. 3-54 9083 (WITH DOLBY ENCODING OPTION) PRODUCT MANUAL 9083-ENC-OM (V4.4)

  • Page 103: Dolby E Internal Metadata

    For an internally generated metadata, individual audio production parametric settings and bitstream mode controls allow setup. Drop-down lists provide on/off settings or selection from a range of appropriate choices in general conformance with ® Dolby encoding and ATSC A/52B practices. 3-55 9083-ENC-OM (V4.4) 9083 (WITH DOLBY ENCODING OPTION) PRODUCT MANUAL...

  • Page 104: Dolby E Channel Mapping

    AES, analog, downmix, mono, or tone generator audio source as shown to the left. • • • • • • • • • • • • 3-56 9083 (WITH DOLBY ENCODING OPTION) PRODUCT MANUAL 9083-ENC-OM (V4.4)
  • Page 105 Note: The AES Audio Out Pairs 5-8 tab is not available or displayed in DashBoard™for the 9083. Instead, the encoded pair (when active) is available as copies on AES Out pairs 5 thru 8 regardless of other output routing selections.

  • Page 106: Example Setups Using The 9083 And Dashboard

    Example Setups Using The 9083 and DashBoard™ Audio Routing Example Using DashBoard™ Figure 3-6 shows an example of using the 9083 Embedded Audio Group and AES Output Pairs functions to de-embed audio, route the audio to discrete outputs for post-production processing, and finally re-embed the audio into the SDI video output.
  • Page 107 SDI data and routed to discrete AES channels 1 thru 5. Also, an internal tone generator (TG1) and two analog inputs are routed to AES channels 6 thru 8, respectively. Figure 3-6 (sheet 2) shows the 9083 control settings that result in this routing.
  • Page 108 Example Setups Using The 9083 and DashBoard™ The discrete AES audio on AES channels 9 thru 16 is now re-embedded using the 9083 control settings shown in Figure 3-6 (sheet 3). 9083ENCD_AUD_ROUTE_EX3A.PNG 9083ENCD_AUD_ROUTE_EX3B.PNG Using the Embedded Audio 9083 SDI OUT...

  • Page 109: Dolby ® Digital™ (Ac-3) Setup And Routing Example (Option +Encd Only)

    ® Dolby Digital™ (AC-3) Setup and Routing Example (Option +ENCD only) ® Figure 3-7 shows an example setup of using the 9083 Dolby controls and audio routing controls to perform the following: • Encode AES channels 1 thru 6 into an AC-3 encoded pair.
  • Page 110 Example Setups Using The 9083 and DashBoard™ Using the External Metadata Source drop-down, select RS-485 external metadata. Remove VBI SMPTE 2020 metadata from the output video by setting Metadata Removal to On . Using the AC-3 Metadata Source drop-down, select Program 1 for AC-3 Metadata Source.

  • Page 111: Dolby ® E Setup And Routing Example (Option +Ence Only)

    Example Setups Using The 9083 and DashBoard™ ® Dolby E Setup and Routing Example (Option +ENCE only) ® Figure 3-8 shows an example setup of using the 9083 Dolby controls and audio routing controls to perform the following: • ®...
  • Page 112 Example Setups Using The 9083 and DashBoard™ Using the External Metadata Source drop-down, select Input Video VBI external metadata. Remove VBI SMPTE 2020 metadata from the output video by setting Metadata Removal to On . Using the On Loss of External Metadata drop-down, select Switch to Internal Metadata Controls as the failover source should the current metadata become unavailable.

  • Page 113: Troubleshooting

    Error and Failure Indicator Overview The 9083 card itself and its remote control systems all (to varying degrees) provide error and failure indications. Depending on how the 9083 card is being used (i.e, standalone or network controlled through DashBoard™...
  • Page 114 Four blue LEDs indicate the input signal raster format being received and locked onto by the 9083 (1080, LEDs 720, 625, 525). Continuous cycling of the LEDs indicates the 9083 has not locked onto a particular format (as in the case of no signal input).
  • Page 115 Specific errors are displayed in the Card Info pane (in this example “No connection to device” indicating 9083 card is not connecting to frame/LAN). If the 9083 card is not connecting to the frame or LAN, all controls are grayed-out (as shown in the example here).
  • Page 116 By clicking on “Slot 7: card is shown here CDI-9083-ENCD RCVR2” in (in this example, all this example, Card Info is indications are OK) shown for 9083 card in slot 7 Where applicable, additional status is displayed (as shown in this example) 9083ENCD_CARD_INFO_ACCESS2.PNG...

  • Page 117: Basic Troubleshooting Checks

    Item Checks Verify power presence and • On both the frame Network Controller Card and the 9083, in all cases when characteristics power is being properly supplied there is always at least one indicator illuminated. Any card showing no illuminated indicators should be cause for concern.

  • Page 118: 9083 Processing Error Troubleshooting

    In the majority of cases, most errors are caused by simple errors where the 9083 is not appropriately set for the type of signal being received by the card. Note: The error indications shown below are typical for the corresponding error con- ditions listed.
  • Page 119 Analog peak audio input on Reduce analog audio level at the source. Audio icon and Analog Input selected input exceeds +24 Note: 9083 audio gain controls cannot be used Clipping message in 9083 dBu level to correct analog input overload condition. Card Info pane.
  • Page 120 • Enable control not turned on • Group Enable button for Embedded Audio Group 1/2 or Embedded Audio Group 3/4 function submenu must be turned on for sources to be embedded into respective embedded channels. 3-72 9083 (WITH DOLBY ENCODING OPTION) PRODUCT MANUAL 9083-ENC-OM (V4.4)
  • Page 121 Make certain this choice is selected only if intended. (See Dolby Digital Encoder (p. 3-43) or Dolby E Encoder (p. 3-51) for more information.) 3-73 9083-ENC-OM (V4.4) 9083 (WITH DOLBY ENCODING OPTION) PRODUCT MANUAL...

  • Page 122: Troubleshooting Network/Remote Control Errors

    The Cobalt Digital Inc. Technical Support Department will continue to provide advice on any product manufactured by Cobalt Digital Inc., beyond the warranty period without charge, for the life of the product. See Contact Cobalt Digital Inc. (p. 1-29) in Chapter 1, “Introduction“ for contact information. 3-74 9083 (WITH DOLBY ENCODING OPTION) PRODUCT MANUAL 9083-ENC-OM (V4.4)

  • Page 123: Chapter 1 Loudness Measurement Guidelines And Techniques

    Measurement Technique – Consideration should be given in using techniques that result in the most meaningful or representative LKFS measurements. These techniques are described below, along with techniques suggestions suitable for various types of program material. 9083-ENC-OM (V4.4) 9083 (WITH DOLBY ENCODING OPTION) PRODUCT MANUAL...

  • Page 124: About Target Lkfs Value

    LKFS measurement can persist, after which an error is indicated. These configurable parameters are described in detail in the tab description for “Audio LKFS Monitor” in Chapter 3,“Operating Instructions”. 9083 (WITH DOLBY ENCODING OPTION) PRODUCT MANUAL 9083-ENC-OM (V4.4)

  • Page 125: Measurement Techniques For Various Program Material Forms

    ATSC A/85. Therefore, techniques appropriate for the material must be applied. This section provides guidance and examples of properly applied techniques for various cases and forms of typical program material. 9083-ENC-OM (V4.4) 9083 (WITH DOLBY ENCODING OPTION) PRODUCT MANUAL...

  • Page 126: Importance Of An Anchor Element

    Figure A-2 shows an example (using a target LKFS of -24.0) where these assumptions can be followed, and an example where certain techniques should be applied in order to obtain a meaningful LKFS assessment. 9083 (WITH DOLBY ENCODING OPTION) PRODUCT MANUAL 9083-ENC-OM (V4.4)
  • Page 127 LKFS measurement that is under-representative of the entire piece. HI Limit Dialnorm LO Limit Material Run Duration (5 min.) Figure A-2 LKFS Measurement/Assessment for Various Program Material Forms 9083-ENC-OM (V4.4) 9083 (WITH DOLBY ENCODING OPTION) PRODUCT MANUAL...

  • Page 128: Specific Measurement Techniques For Various Material Forms

    As long as the material does not have loudness pauses exceeding half the overall run time (which is typically unlikely), a simple observation over the course of the material will typically provide a very reliable LKFS measurement. 9083 (WITH DOLBY ENCODING OPTION) PRODUCT MANUAL 9083-ENC-OM (V4.4)

  • Page 129: Modifying Lkfs Assessments Using Parametric Settings

    Note: Assessment for negative-going LKFS trend behaves accommodates deviations from target for identically as those shown above. longer loiter periods without registering an LKFS error. Figure A-4 Modifying LKFS Threshold Error Alert Parameters 9083-ENC-OM (V4.4) 9083 (WITH DOLBY ENCODING OPTION) PRODUCT MANUAL...
  • Page 130 LKFS high error insertion does not result in Consistenty low LKFS local nuisance LKFS LO error insertion eventually results in LKFS low error Figure A-5 Long-Form Simplified Measurement 9083 (WITH DOLBY ENCODING OPTION) PRODUCT MANUAL 9083-ENC-OM (V4.4)
  • Page 132 Cobalt Digital Inc. 2406 E. University Ave. Urbana, IL 61802 Voice 217.344.1243 • Fax 217.344.1245 www.cobaltdigital.com 9083-ENC-OM (V4.4) Printed in USA...
