9922-2FS
9922-2FS
3G/HD/SD-SDI Dual-Channel Frame Sync
with Audio/Video Processing, AES/Analog Audio Embedding/
De-Embedding, and CVBS I/O
Product Manual
Cobalt Digital Inc.
2506 Galen Drive
Champaign, IL 61821
Voice 217.344.1243 • Fax 217.344.1245
www.cobaltdigital.com
9922-2FS-OM (V1.8)
