  • Page 1 EDH3497TDS Tumble Dryer User Manual...
  • Page 2: Table Of Contents

    13. TECHNICAL DATA..................19 WE’RE THINKING OF YOU Thank you for purchasing an Electrolux appliance. You’ve chosen a product that brings with it decades of professional experience and innovation. Ingenious and stylish, it has been designed with you in mind. So whenever you use it, you can be safe in the knowledge that you’ll get great results every time.
  • Page 3: Safety Information

    ENGLISH SAFETY INFORMATION Before beginning the installation and use of this appliance, carefully read the supplied instructions. The manufacturer is not responsible for any injuries or damages that are the result of incorrect installation or usage. Always keep the instructions in a safe and accessible location for future reference.
  • Page 4 Read it carefully before installation (Refer to the Installation leaflet). The appliance can be installed as freestanding or • below the kitchen counter with correct space (Refer to the Installation leaflet).
  • Page 5: Safety Instructions

    ENGLISH Items that have been soiled with substances such as • cooking oil, acetone, alcohol, petrol, kerosene, spot removers, turpentine, waxes and wax removers should be washed in hot water with an extra amount of detergent before being dried in the tumble dryer. Items such as foam rubber (latex foam), shower caps, •...
  • Page 6 2.5 Care and cleaning • Do not use multi-plug adapters and extension cables. • Do not pull the mains cable to WARNING! disconnect the appliance. Always pull Risk of injury or damage to the mains plug. the appliance. • Do not touch the mains cable or the •...
  • Page 7: Product Description

    ENGLISH 3. PRODUCT DESCRIPTION Water container Control panel Internal light Appliance door Primary Filter The button to open the heat exchanger door Airflow slots Adjustable feet Heat exchanger door Heat exchanger cover The knob to lock the heat exchanger cover Rating plate For ease of loading laundry or ease of installation the...
  • Page 8: Programme Table

    Dryness touchpad Touch the touchpads with your finger in the area with On/Off button the symbol or name of the option. Do not wear gloves when you operate with the control panel. Make sure that the control panel is always clean and dry.
  • Page 9 ENGLISH Load (max.) Programmes Type of load Fabric mark Cotton and synthetic fabrics. Low tem‐ perature programme. Delicate pro‐ Mixed 3kg/ gramme with warm air. Drying level: Extra Dry, Cupboard Synthetic 3,5kg/ Iron Dry Easy care fabrics for which a minimum of ironing is necessary.
  • Page 10: Options

    Load (max.) Programmes Type of load Fabric mark Easy care fabrics for which a minimum of ironing is necessary. The drying results can be different from one type of fabric to 1,5kg (or 7 the other. Shake the items before you Shirts put them in the appliance.
  • Page 11 ENGLISH 6.4 Rack Time Drying • Cupboard Dry+ (for Cotton only) • Cupboard Dry This option is applicable only to the Drying Rack programme. You can set the • Iron Dry programme duration, from a minimum of 30 minutes to a maximum of 4 hours. 6.7 MyFavourite The setting of the duration is related to the quantity of laundry in the appliance.
  • Page 12: Settings

    Programmes ■ Shirts Duvets ■ Jeans ■ Sports 1) Together with the program you can set 1 or more options. To activate or deactivate them, press the related touchpad. 2) Only with the Drying Rack (standard accessory or optional, depending on model).
  • Page 13: Before First Use

    ENGLISH • the more dry laundry Deactivating the water container indicator: • the standard dry laundry 4. Press the button (E) again and again 1. Press the on/off button to activate the until the indicator of the correct level appliance. comes on.
  • Page 14 3. Set the correct programme and • An intermittent acoustic signal options for the type of load. operates. The display shows the programme • The indicator flashes. duration. • The indicator flashes. The drying time you see is • The Start/Pause indicator is on.
  • Page 15: Hints And Tips

    ENGLISH 10. HINTS AND TIPS 10.1 Preparing the laundry • Use suitable programme for cottons, jersey and knitwear to prevent • Close the zippers. shrinkage. • Close the fasteners of duvet covers. • Do not exceed the maximum load • Do not dry ties or ribbons loose (e.g. stated in programmes chapter or apron ribbons).
  • Page 16: Emptying The Water Container

    5. 1) 1) If necessary clean the filter with tap warm water using a brush and/or a vacuum cleaner. 11.2 Emptying the water container You can use the water from the water container as an alternative to distilled water (e.g.
  • Page 17: Cleaning The Control Panel

    ENGLISH 11.5 Cleaning the control panel CAUTION! and housing Do not touch the metal surface with bare hands. Use a standard neutral soap detergent to Risk of injury. Wear clean the control panel and housing. protective gloves. Clean Use a moist cloth to clean. Dry the carefully to avoid damaging cleaned surfaces with a soft cloth.
  • Page 18: Troubleshooting

    12. TROUBLESHOOTING Problem Possible solution You cannot activate the appliance. Make sure that the mains plug is connec‐ ted to the mains socket. Check fuse in fuse box (domestic installa‐ tion). The programme does not start. Press Start/Pause. Make sure that the appliance door is closed.
  • Page 19: Technical Data

    ENGLISH • The drum is dirty. • The airflow slots are clogged. • Incorrect setting of the conductivity • Room temperature is too low or too Settings - sensor ( See chapter " high ( optimal room temperature 19°C Adjustment of the remaining laundry to 24°C ) moisture degree "...
  • Page 20: Consumption Data

    13.1 Consumption data Energy Programme Spun at / residual humidity Drying time consump‐ tion Cotton 9 kg Cupboard Dry 1400 rpm / 50% 175 min. 2,00 kWh 1000 rpm / 60% 200 min. 2,28 kWh Iron Dry 1400 rpm / 50% 121 min.
  • Page 21 ENGLISH...
  • Page 22 www.electrolux.com...
  • Page 23 ENGLISH...
  • Page 24 www.electrolux.com/shop...
