- Page 1 plug & drive COPPER INSTALLATION GUIDE COPPER - installation guide COPPER - installation guide WBCP-C-IG-001-EN...
-
Page 2: Table Of Contents
Disregard of or actions contrary to the safety information and instructions contained in this manual and printed on the device may lead to electric shock, fire and/or severe injury and either damage to the vehicle’ s battery or to the Wallbox device. Any resulting damage from such actions is excluded from the warranty. -
Page 3: Safety Instructions
The Wallbox chargers can only be used under the specified operating parameters and within the normal environmental conditions described on Product description. • Do not use your Wallbox charger under inclement weather conditions that could affect either the vehicle or the Wall- box device. Do not open the connector panel cover in the rain. CONNECTOR RECOMMENDATIONS •... -
Page 4: Product Description
• The Wallbox device is an smart charger provided with connectivity functionalities. Wallbox software allows our technical support service to solve any issue remotely, no wait times and no need to set appoint- ments and almost instantaneously The Wallbox device is provided with an specific Electric Vehicle Connector (EVC). Depending on the version acquired it comes equipped with: •... - Page 5 QR code Serial Number CE marking Product Number Disposal information Network settings The Wallbox charger components delivered must comply the following list ¹ : • Wallbox Copper • Holder • Installation Guide • Drilling templates Mounting components: 4x 6,3x40mm Screws Required tools: 4x Ø8mm Wallanchors...
-
Page 6: Installation Instructions
Please contact an electrician or arrange installation at your premises with your local distributor. PRECAUTIONS Take special care while selecting the mounting surface, it has to be constructed in order to withstand your Wallbox weight and the mechanical forces associated with the charging process. -
Page 7: Dimensions & Positioning
Its is compulsory to consider the following precautions: • The required mounting area for the Wallbox charging station is at least 250 x 150 mm (H x W). • When mounting the Wallbox, the cable should easily reach the charging port. -
Page 8: Drill & Mount
Step 0: In the backside of the wallbox charger you will find an insertion with a thinner wall; use a cutter, razor or a sharp tool and carefully make an incision into the cable opening. Please meticulously remove all sharp edges. Take a Rutaseal bushing and install it. - Page 9 DRILL & MOUNT Step 3: Insert the mains supply cable through the bushing (as pictured) Step 4: Connect the power lines, neutral and protective earth using the terminal blocks provided Three Phase Configuration One Phase Configuration From left to right: From left to right: L1,L2 &...
-
Page 10: Startup
Remeber to ensure that the power supply is turned off, before start cleaning your charger. • In case you want to clean your Wallbox, we recommned you to use a soft, dry or damp cloth. Do not use a spray or direct water to clean your Wallbox charger.
