- Page 1 4KCVH2H 4K HDMI Audio Extractor User Manual...
- Page 3 AV Access Technology Limited assumes no responsibility for any inaccuracies that may be contained in this document. AV Access Technology Limited also makes no commitment to update or to keep current the information contained in this document.
-
Page 4: Important Safety Instructions
Important Safety Instructions Do not expose this apparatus to rain, moisture, dripping or splashing. No objects filled with liquids, such as vases, shall be placed on the apparatus. Do not install or place this unit in a bookcase, built-in cabinet, or in another ... -
Page 5: Table Of Contents
Table of Contents Overview ....................... 3 Package Contents ........................4 Front Panel ..........................5 Rear Panel ..........................5 EDID Management ....................6 Installation Instructions ..................8 Specification ......................9 Trouble Shooting ....................10 Warranty ......................11 www.avaccess.com... -
Page 6: Overview
Overview Overview 4KCVH2H is a 4K HDMI audio extractor with resolutions up to 4K@60Hz (chroma sub-sampling 4:4:4 8-bit) and HDCP 2.2. Its digital or analog audio output allows audio to be de-embedded from HDMI input and sent to audio distribution system, such as AVR or Zone Amplifier. Its rotary EDID switch has 16 EDID presets for EDID management. -
Page 7: Package Contents
Overview Package Contents Before you start the installation of the product, please check the package contents: 4KCVH2H x 1 Power Adapter (DC 12V 0.5A) x 1 Mounting Brackets x 2 User Manual x 1 www.avaccess.com... -
Page 8: Front Panel
Overview Front Panel Name Description HDMI Out Connects to an HDMI display Rear Panel Name Description Power Connecter Connects to the DC 12V 0.5A power adapter. ON: The device is powered on. Power LED OFF: The device is powered off. HDMI In Connects to an HDMI source. -
Page 9: Edid Management
EDID Management EDID Management EDID (Extended Display Identification Data) is a data structure provided by a digital display to describe its capabilities to a video source. The product features an EDID management that can be used when the EDID dosen't meet the installation requirements. - Page 10 EDID Management source device. In order to achieve a better user experience, please refer to the following audio support descriptions for EDID setting during installation. 1. Switch the EDID to position 0——Copy EDID from HDMI out. 3.5mm Analog TV Audio HDMI Audio SPDIF Audio Stereo Audio...
-
Page 11: Installation Instructions
Installation Instructions Installation Instructions Instructions: The HDMI source contains many kinds of device such as Apple TX, STB, Xbox, Media player, Blu-ray player, DVD player, etc. The HDMI display contains many kinds of device such as TV, Monitor, Video ... -
Page 12: Specification
Specification Specification Technical HDMI up to 4K@60Hz (4:4:4 8-bit) with HDCP Video Signal Type 2.2. PCM 2.0/5.1/7.1, Dolby TureHD and DTS HD Audio Format Master Audio VESA: 800x600@60Hz, 1024x768@60Hz, 1280x768@60Hz, 1280x800@60Hz, 1280x960@60Hz, 1280x1024@60Hz, 1360x768@60Hz, 1366x768@60Hz, 1440x900@60Hz, 1600x900@60Hz, Input/Output Resolution 1600x1200@60Hz, 1680x1050@60Hz, Support 1920x1200@60Hz;... -
Page 13: Trouble Shooting
Trouble Shooting (W x H x D) 4.74'' x 0.79'' x 3.17'' Product Weight 0.23kg Trouble Shooting Five Steps of Regular Troubleshooting Routine Power: Please make sure all devices are powered on (source, extractor, display device). Indicator: Please make sure power LED is normal powered on. Devices: Please make sure pictures can be shown normally when connecting source to display devices directly. -
Page 14: Warranty
The warranty has expired. The defects are caused by the fact that the product is repaired, dismantled or altered by anyone that is not from an AV Access Technology Limited authorized service partner. The defects are caused by the fact that the product is used or handled improperly, roughly or not as instructed in the applicable User Guide. - Page 16 AV Access Technology Limited V1.0.2...
