- Page 1 4K IP Encoder with 4 HDMI Inputs 4KIP204E User Manual...
- Page 2 Table of Contents Introduction ..................2 Overview ........................2 Features ........................2 Package Contents ....................2 Panel .......................... 3 Installation and Application ............... 3 Bracket Installation ....................3 Application ......................3 Specifications ..................5 Warranty ....................6 www.avaccess.com info@avaccess.com...
- Page 3 Introduction Overview This product is a four-in-one 4K IP encoder that includes 4 HDMI inputs with resolutions supported up to 3840x2160p@30Hz. It provides flexible control options of front panel buttons and VDirector App (IOS/Android/Windows version). It is ideal for applications in sports bars, conference rooms, shopping malls, digital signage, etc., especially for places with limited installation and deployment space.
- Page 4 Panel Input Source Display On/Off Selection Buttons Buttons Power LED Status LED Reset Power Reset HDMI In Connector Installation and Application Note: Disconnect all devices from power before installation. Bracket Installation Steps to install the device in a suitable location: 1.
- Page 5 (Note: to get Android version, please visit Google Play Store; to get Windows version, please visit www.avaccess.com) Connect all encoders, decoders and the wireless router to the network switch according to the following diagram shown: Configure the wireless router properly, and then connect your iPad to the Wi-Fi network.
- Page 6 Name Description Logo This logo can be changed to a new one. System Click this button to enter system configuration page for the Configuration functions: 1) Naming and Sequencing; 2) Video Wall Settings; Button 3) Advanced Settings; 4) System Information. Shows the list of online RX devices, including single device RX List and devices for video walls.
- Page 7 2. The warranty has expired. 3. The defects are caused by the fact that the product is repaired, dismantled or altered by anyone that is not from an AV Access Technology Limited authorized service partner. The defects are caused by the fact that the product is used or handled improperly, roughly or not as instructed in the applicable User Guide.
