Summary of Contents for AV Access 4KIPJ200E

  • Page 1 4K@60Hz KVM over IP Encoder or Decoder 4KIPJ200E or 4KIPJ200D User Manual...
  • Page 3: Table Of Contents

    Table of Contents Introduction ......................2 Overview ............................2 Features ............................2 Package Contents ........................3 Panel .............................. 4 Encoder ..........................4 Decoder ..........................5 Installation and Application................... 6 Bracket Installation ........................6 Application ..........................7 Hardware Installation ..................... 8 Specification ......................
  • Page 4: Introduction

    Introduction Introduction Overview 4KIPJ200 series encoders and decoders are designed for UHD media up to 3840 x 2160@60Hz 4:4:4 to be switched and distributed over standard Gigabit Ethernet networks, providing complete end-to-end streaming systems, where HDMI along with USB, RS232 can be routed separately or as a whole. HDCP 2.2/2.3 specifications are employed.
  • Page 5: Package Contents

    Introduction to-multipoint applications. Supports PoE to be remotely powered by compatible power source equipment  such as a PoE-enabled Ethernet switch, eliminating the need for a nearby power outlet. Supports user-selectable output HDCP configuration via the HDIP-IPC  Controller. Decoders provide video fit in/stretch out modes and rotation options for video ...
  • Page 6: Panel

    Introduction Panel Encoder Front Panel Name Description On: The device is powered on.  Link LED Blinking: The device is booting.  Off: The device is powered off.  On: The device is connected to an active video source.  Status LED Blinking: The device is not connected to a video source.
  • Page 7: Decoder

    Introduction Decoder Front Panel Name Description On: The device is powered on.  Power LED Blinking: The device is booting.  Off: The device is powered off.  On: The device is connected to an encoder and the video is ...
  • Page 8: Installation And Application

    Installation and Application Installation and Application Bracket Installation Note: Before installation, make sure both devices are disconnected from the power source. Steps to install the device on a suitable location: Attach the mounting brackets to the panels of both sides using the screws (two on each side) provided in the package.
  • Page 9: Application

    Installation and Application Application Application 1 Ethernet Switch Amplifier Apple TV Encoder HDMI IN AUDIO OUT Decoder 3 x 3 Video Wall HDMI Set-top Box Encoder HDMI IN Decoder Serial HDMI 4K Media Player HDMI IN Encoder 4 x 5 Video Wall Decoder HDMI Workstation/PC...
  • Page 10: Hardware Installation

    Hardware Installation Application 2 Ethernet Switch Apple TV Encoder HDMI IN 7.1 Surround Sound System Display Set-top Box Encoder Decoder HDMI IN HDMI OUT HDMI OUT 4K Media Player Encoder HDMI IN Display Workstation/PC Decoder Encoder HDMI IN USB(PC) HDMI OUT IP Controller Display the Third Party Device...
  • Page 11: Specification

    Specification Specification Encoder Technical Input Video Port 1 x female HDMI type A (19 pins) Input Video Type HDMI 2.0, HDCP 2.2/2.3 3840 x 2160p@24Hz 4:4:4, 3840 x 2160p@30Hz 4:4:4, 3840 x 2160p@50Hz 4:4:4, 3840 x 2160p@60Hz 4:4:4, 640 x 480p@60Hz, 720 x 480p@60Hz, 1280 x 720p@60Hz, 1920 x 1080i@60Hz, 1920 x 1080p@60Hz, 720 x 576p@50Hz, 1280 x 720p@50Hz, 1920 x 1080i@50Hz, 1920 x 1080p@50Hz, 1920 x 1080p@24Hz, 1920 x 1080p@25Hz, 640 x 480@60Hz,...
  • Page 12: Decoder

    Specification General Power Supply DC 12V 2A; PoE Power Consumption 7W (Max) Unit Dimensions 215 mm x 25 mm x 120 mm / 8.46'' x 0.98'' x 4.72'' (W x H x D) Unit Net Weight 0.74kg/1.63lbs (without accessories) Decoder Technical Input Video Port 1 x female RJ-45...
  • Page 13: Control Of Devices

    Control of Devices General Operating Temperature 0 to 45°C (32 to 113 °F), 10% to 90%, non-condensing Storage Temperature -20 to 70°C (-4 to 158 °F), 10% to 90%, non-condensing Human Body Model: ESD Protection ±8kV (air-gap discharge)/±4kV (contact discharge) Power Supply DC 12V 2A;...
  • Page 14: Osd Menu Operation

    OSD Menu Operation OSD Menu Operation The OSD menu is designed for a decoder to associate with a specified encoder quickly and easily. Here is how it works. Connect a USB keyboard and/or a mouse to the USB-A port(s) of a certain decoder.
  • Page 15: Warranty

    Products are backed by a limited 1-year parts and labor warranty. For the following cases AV Access shall charge for the service(s) claimed for the product if the product is still remediable and the warranty card becomes unenforceable or inapplicable.

This manual is also suitable for:

4kipj200d
